A correct method of configuring Samba for browsing SMB shares in a home network

SMB
SMB (Server Message Block) is the underlying protocol that Microsoft Windows computers use to connect to resources, such as file shares and printers, and to transfer information when the connections are established. Samba is the Linux implementation of SMB that allows file and printer information to be transferred between Windows and Linux computers. An early variant of the SMB protocol is known as ‘CIFS’ (Common Internet File System). CIFS is actually obsolete, so the correct term to use these days is ‘SMB’ (see the blog post Why You Should Never Again Utter The Word, "CIFS"), although ‘CIFS’ is still used sometimes when referring to SMB.

Terminology
You are likely to come across several terms when reading about Samba, such as NetBIOS, Active Directory (AD), Lightweight Directory Access Protocol (LDAP), Kerberos, Windows Internet Name Service (WINS) and Winbind, to name but a few. Most are used in larger corporate or enterprise networks but you can ignore most of them – only broadcast NetBIOS name resolution or WINS are necessary to configure Samba in small home networks. For example, my home network uses broadcast NetBIOS name resolution and sometimes has up to 15 devices connected (Linux, Windows 7/10, macOS, Android and iOS), all of which can browse file shares using SMB/Samba.

Note: You should not use Broadcast NetBIOS Name Resolution and WINS at the same time.

To explain the terminology – Active Directory is a central database of user accounts and passwords used primarily in Windows networks to authenticate users, and LDAP is the protocol that clients and servers use to access the Active Directory database. Kerberos is a separate encrypted authentication mechanism used for client-server applications, such as computers that access a specific file or web server, or SQL database. WINS is a mechanism for storing Windows computer name to IP address mappings on a central server – the WINS Server. Computers in a LAN interrogate the WINS server to obtain the IP addresses of other computers. It’s a bit like DNS except that the WINS Server stores Windows computer names rather than URLs or domain names. Winbind is a Unix/Linux mechanism that allows Windows NT accounts to look like a Unix service to Unix/Linux machines.

NetBIOS
How is NetBIOS relevant to Samba? Samba uses NetBIOS in three different ways:

  1. NetBIOS over UDP Port 137 to advertise Windows computer names for name to IP address resolution;

  2. NetBIOS over UDP Port 138 to advertise services that the computer offers and to elect a ‘Master Browser’ (explained below);

  3. SMB over NetBIOS over TCP/IP Port 139 to connect to file shares or printers. Once connected, the computers may negotiate using SMB direct over TCP/IP Port 445 to improve efficiency of the connection.

NetBIOS over UDP (Port 137) is a connectionless broadcast protocol that Windows machines use to advertise over the LAN their names and corresponding IP addresses. Other computers receive the broadcasts and cache the names and IP addresses in a name to IP address mapping table.

NetBIOS over UDP (Port 138) is a connectionless broadcast protocol that Windows machines use to advertise their eligibility to become the Master Browser or Backup Browser for a Windows Workgroup in the LAN. An automatic election process elects only one machine in a Workgroup to become the Master Browser for that workgroup, and elects one or more ‘Backup Browsers’ in the Workgroup. The Master Browser and Backup Browser(s) collate a list of all the computers in the Workgroup and the services that they offer. It is more efficient for a single computer to assume the master role and to collate the information than it is for the information to remain distributed. When you click on ‘Network’ in File Explorer’s ‘Network Neighbourhood’ window, your computer interrogates the Master Browser(s) to obtain a list of the Windows Workgroups in the LAN, the members of the Workgroup(s) and the file and printer services that each Workgroup member offers. If the Master Browser fails or is disconnected, a re-election takes place and a new Master Browser is elected from the list of Backup Browsers in that Workgroup. The same process occurs if you are using a Linux file manager (Dolphin in KDE, Nautilus in GNOME, etc.) with Samba. You can configure the ‘priority’ of the Samba server in each machine in the Workgroup so that it is either more likely or less likely to be elected the Master Browser for the Workgroup. You could even configure Samba on a Linux machine so that it will never be a Master Browser. (It is also possible to configure a Windows machine so that it will never be a Master Browser.)

     Renamed ‘Entire Network’ in some versions of Windows.
     Renamed ‘My Network Places’ or simply ‘Network’ in some versions of Windows.

SMB over NetBIOS over TCP/IP (Port 139) is a connection orientated protocol that Windows computers use to connect to file shares and printers, to retrieve directory listings and to transfer files. Having obtained a list of computers and file shares from the Master Browser, if you click on a particular file share to connect to it, your computer looks up the name of the target computer in the local name table, obtains the target computer’s IP address and initiates a SMB over NetBIOS over TCP/IP connection to it. The target computer then issues a username and password prompt for you to complete the connection. If authentication is successful, the SMB protocol is used to transfer a directory listing of the contents of the share. If you drag and drop a file from the share to your local machine, or vice-versa, SMB is used to transfer the file. Behind the scenes, during the initial connection set-up, your computer and the target carry out a negotiation. If both machines support SMB direct over TCP/IP, the directory listing and subsequent file transfer are transported using SMB over TCP/IP Port 445. This is much more efficient because it eliminates completely the NetBIOS overhead.

When you install and configure Samba on a Linux computer, the ‘smbd‘ and ‘nmbd‘ daemons enable all of the functionality above. In a small network you do not need to enable or use AD, LDAP, Kerberos, WINS, Winbind or anything else for that matter. Samba and its built-in NetBIOS mechanisms will allow you to participate in a Windows Workgroup environment to share and use folders, files and printers.

Workgroups
The majority of Windows computers running in home networks are configured, by default, in a single Workgroup. A Workgroup is a simple way for computers in small networks to advertise and share resources, such as folders and printers, with other members of the same group. You can configure multiple Workgroups in the same LAN but each computer can belong to only one Workgroup. The theory is that different computers can share different resources within their group.

Please Note: A Windows Workgroup is not the same thing as a Windows HomeGroup. The latter concept was introduced in Windows 7 and is an ‘evolution’ of the Workgroup concept, in which you share folders and files but specify a pre-determined group password. All computers wishing to join the HomeGroup specify the same password to connect to the resources in that group. Samba does not participate in Windows HomeGroups because the latter is a Windows-only feature.

Configuring Samba
Firstly, install Samba on the Linux computer. Use Samba 4 and avoid Samba 3, which is obsolete. I have several laptops and a Network Addressable Storage (NAS) server, all running Linux with various releases of Samba 4. I also have a desktop computer running Windows 10 for family use. In addition, family and friends connect various laptops running Windows 7 and Windows 10 to my home network, as well as tablets and smartphones (see How to Access Shared Windows Folders on Android, iPad, and iPhone). This NAS runs 24/7 so I could have configured Samba to always make it the Master Browser but this is not necessary as the remaining computers in the network will elect a new Master Browser should the NAS fail.

Below is a summary of the steps to configure Samba in a Windows Workgroup:

  1. Configure the same Workgroup name on all of the Windows computers (for example, How to Change Workgroup in Windows 10). The default Windows 10 Workgroup is called ‘WORKGROUP‘. In the example further down I used the Windows GUI to change the Workgroup name to ‘GREENGABLES‘. There is plenty of information on the Internet about how to configure Windows file sharing so I won’t repeat any of it here (for example, How to Enable Network Discovery and Configure Sharing Options in Windows 10 and How to set up file sharing on Windows 10 (Share files using File Explorer)).

  2. Configure Samba on the Linux machines by editing the file ‘/etc/samba/smb.conf‘ on each. The contents of the file ‘smb.conf‘ are shown below for a Linux NAS and two Linux laptops. The NetBIOS name of the NAS is ‘akhanaten‘ and the laptops are ‘tutankhamun‘ and ‘smenkhkare‘. You can use either of the smb.conf files of the two laptops as a template for the smb.conf file of any Linux computer in your own home network. You can ignore the smb.conf file of the NAS if you simply want to be able to browse SMB/Samba shares on other computers in your home network.

  3. Use the command ‘pdbedit‘ on each Linux machine to define and configure the Samba users on that machine. The command ‘smbpasswd‘ is an alternative to ‘pdbedit‘ but I recommend you use the latter, as ‘smbpasswd‘ is deprecated. Each Samba user must exist as a Linux user because it is the Linux users who own the shares and are used for authentication.

  4. The NAS has Linux users ‘anne‘, ‘marilla‘, ‘matthew‘ and ‘guest‘, whereas each of the laptops has a Linux user ‘anne‘. The user name does not have to be the same on different computers.

  5. The purpose of each variable in ‘smb.conf‘ is explained on the applicable Samba manual page (enter the command ‘man smb.conf‘ in a terminal window) and the Samba documentation page for smb.conf on the Web.

Furthermore, make sure the Winbind daemon is not running. If Winbind is installed, make sure the service is not running and is disabled.

smb.conf of NAS running Ubuntu Server Edition:

[global]
# SMB uses ports 139 & 445, as explained in this blog post
smb ports = 139 445
netbios name = akhanaten
workgroup = greengables

# Use either NetBIOS broadcast for name resolution or entries in the /etc/hosts file
name resolve order = bcast host

# Don't care if the workgroup name is upper or lower case
case sensitive = no

# User authentication is used to access the shares
security = user
map to guest = bad user
guest account = guest

# Don't allow the use of root for network shares
invalid users = root

# Domain master only applies to LANs that are inter-connected across a WAN
domain master = no

# This machine is eligible to be a Master Browser and its priority is 4
# (the higher the os level, the more preferred to be Master Browser)
# (the maximum allowable value for os level is 255)
preferred master = yes
os level = 4
dns proxy = no

# Always advertise the shares automatically
auto services = global

# Interfaces on which to listen for NetBIOS broadcasts and to allow SMB connections
# Include "lo" because it is the internal interface
# em1 is the name of the Ethernet interface, found using the ifconfig command
interfaces = lo em1
bind interfaces only = yes
log file = /var/log/samba/log.%m
max log size = 1000
syslog = 0

panic action = /usr/share/samba/panic-action %d
server role = standalone server
passdb backend = tdbsam
obey pam restrictions = yes

# Don't synchronise the Linux and Samba user passwords - they can be different
unix password sync = no
passwd program = /usr/bin/passwd %u
passwd chat = *Enter\snew\s*\spassword:* %n\n *Retype\snew\s*\spassword:* %n\n *password\supdated\ssuccessfully* .
pam password change = yes

# This Samba configuration does not advertise any printers
load printers = no

# File to map long usernames to shorter Unix usernames, if necessary
username map = /etc/samba/smbusers

# Allow guest user access if specified in the shares
guest ok = yes

# First user share is called "anne" - only user "anne" specified below can connect to the share
[anne]
comment = "anne share"
path = /nas/shares/anne
writeable = yes
valid users = anne

# Second user share is called "marilla" - only user "marilla" specified below can connect to the share
[marilla]
comment = "marilla share"
path = /nas/shares/marilla
writeable = yes
valid users = marilla

# Third user share is called "matthew" - only user "matthew" specified below can connect to the share
[matthew]
comment = "matthew share"
path = /nas/shares/matthew
writeable = yes
valid users = matthew

# Fourth user share is called "guest" - any user can connect to the share
[guest]
comment = "guest account"
path = /nas/shares/guest
writeable = yes
guest ok = yes

smb.conf of laptop #1 running Gentoo Linux:

[global]
;no need to specify 'smb ports' as ports 139 & 445 used by default
workgroup = GREENGABLES
netbios name = tutankhamun
case sensitive = no
browseable = yes

;If this machine becomes a Master Browser, the following parameter allows it to hold the browse list
browse list = yes

printcap name = cups
printing = cups

log file = /var/log/samba/log.%m
max log size = 50

security = user
map to guest = bad user

encrypt passwords = yes
passdb backend = tdbsam

domain master = no
local master = yes
preferred master = yes
; os level = 6 on the other laptop, so I have made it 5 on this laptop.
os level = 5
name resolve order = bcast
wins support = no
dns proxy = no

;Listen for NetBIOS on Ethernet and Wireless interfaces
;Names of the interfaces found using ifconfig command
interfaces = enp4s0f1 wlp3s0

[netlogon]
comment = Network Logon Service
path = /var/lib/samba/netlogon
guest ok = yes

[printers]
comment = All Printers
path = /var/spool/samba
guest ok = yes
printable = yes
create mask = 0700

[print$]
path = /var/lib/samba/printers
write list = @adm root
guest ok = yes

[anne-share]
path = /home/anne/anne-share/
guest ok = yes
;read only = no
writeable = yes
browseable = yes
valid users = anne

[Public]
path = /home/anne/Public/
guest ok = yes
;read only = no
writeable = yes
browseable = yes

smb.conf of laptop #2 running Gentoo Linux:

[global]
;no need to specify 'smb ports' as ports 139 & 445 used by default
workgroup = GREENGABLES
netbios name = smenkhkare
case sensitive = no
browseable = yes

;If this machine becomes a Master Browser, the following parameter allows it to hold the browse list
browse list = yes

printcap name = cups
printing = cups

log file = /var/log/samba/log.%m
max log size = 50

security = user
map to guest = bad user

encrypt passwords = yes
passdb backend = tdbsam

domain master = no
local master = yes
preferred master = yes
; os level = 5 on the other laptop so I have made it 6 on this laptop
os level = 6
name resolve order = bcast
wins support = no
dns proxy = no

;Listen for NetBIOS on Ethernet and Wireless interfaces
;Names of the interfaces found using ifconfig command
interfaces = eth0 wlan0

[netlogon]
comment = Network Logon Service
path = /var/lib/samba/netlogon
guest ok = yes

[printers]
comment = All Printers
path = /var/spool/samba
guest ok = yes
printable = yes
create mask = 0700

[print$]
path = /var/lib/samba/printers
write list = @adm root
guest ok = yes

[anne-share]
path = /home/anne/share-share/
guest ok = yes
;read only = no
writeable = yes
browseable = yes
valid users = anne

[Public]
path = /home/anne/Public/
guest ok = yes
;read only = no
writeable = yes
browseable = yes

Samba Commands
The following are Samba commands you can use on any of the Linux computers to find information on the Samba shares.

The ‘smbtree‘ command lists the computers currently using SMB in the local network:

user $ smbtree
GREENGABLES
        \\AKHANATEN                     Samba 4.3.11-Ubuntu
                \\AKHANATEN\IPC$                IPC Service (Samba 4.3.11-Ubuntu)
                \\AKHANATEN\guest               guest account
                \\AKHANATEN\matthew             matthew share
                \\AKHANATEN\marilla             marilla share
                \\AKHANATEN\anne                anne share
        \\SMENKHKARE                    Samba 4.2.14
                \\SMENKHKARE\Samsung_CLX-8385ND Samsung CLX-8385ND
                \\SMENKHKARE\Canon_MP510_Printer        Canon MP510 Printer
                \\SMENKHKARE\Virtual_PDF_Printer        Virtual PDF Printer
                \\SMENKHKARE\Canon_MP560_WiFi   Canon MP560 WiFi
                \\SMENKHKARE\IPC$               IPC Service (Samba 4.2.14)
                \\SMENKHKARE\Public
                \\SMENKHKARE\anne-share
                \\SMENKHKARE\print$
                \\SMENKHKARE\netlogon           Network Logon Service
        \\TUTANKHAMUN                   Samba 4.2.11
                \\TUTANKHAMUN\Samsung_Xpress_C460FW     Samsung Xpress C460FW
                \\TUTANKHAMUN\Canon_MP560_Printer       Canon PIXMA MP560
                \\TUTANKHAMUN\Canon_MP510_Printer       Canon PIXMA MP510
                \\TUTANKHAMUN\Virtual_PDF_Printer       Virtual PDF Printer
                \\TUTANKHAMUN\IPC$              IPC Service (Samba 4.2.11)
                \\TUTANKHAMUN\Public
                \\TUTANKHAMUN\anne-share
                \\TUTANKHAMUN\print$
                \\TUTANKHAMUN\netlogon          Network Logon Service
HOME
        \\BTHUB5                        BT Home Hub 5.0A File Server
                \\BTHUB5\IPC$                   IPC Service (BT Home Hub 5.0A File Server)

BTHUB5‘ is a BT Home Hub 5 (a network router and broadband modem). Notice that it is configured by default to be in a Windows Workgroup named ‘HOME‘. The BT Home Hub 5 has a USB port to which an external USB HDD could be attached, so I assume computers in the home network could have been configured to use the HOME Workgroup instead of GREENGABLES and hence access that USB HDD, i.e. use it as a NAS. However, no HDD is attached to the BT Home Hub 5, so just ignore the BTHUB5 device and the HOME Workgroup.

The ‘nmblookup‘ command is used to see which services each computer offers. The strings ‘..__MSBROWSE__.‘ and ‘<1d>‘ in the output indicate that the computer is currently the Master Browser (see the Microsoft TechNet article NetBIOS Over TCP/IP for details):

user $ nmblookup akhanaten
192.168.1.70 akhanaten<00>

user $ nmblookup -A 192.168.1.70
Looking up status of 192.168.1.70
        AKHANATEN       <00> -         B <ACTIVE>
        AKHANATEN       <03> -         B <ACTIVE>
        AKHANATEN       <20> -         B <ACTIVE>
        GREENGABLES     <00> - <GROUP> B <ACTIVE>
        GREENGABLES     <1e> - <GROUP> B <ACTIVE>

        MAC Address = 00-00-00-00-00-00

user $ nmblookup tutankhamun
192.168.1.79 tutankhamun<00>

user $ nmblookup -A 192.168.1.79
Looking up status of 192.168.1.79
        TUTANKHAMUN     <00> -         B <ACTIVE>
        TUTANKHAMUN     <03> -         B <ACTIVE>
        TUTANKHAMUN     <20> -         B <ACTIVE>
        GREENGABLES     <00> - <GROUP> B <ACTIVE>
        GREENGABLES     <1e> - <GROUP> B <ACTIVE>

        MAC Address = 00-00-00-00-00-00

user $ nmblookup smenkhkare
192.168.1.90 smenkhkare<00>

user $ nmblookup -A 192.168.1.90
Looking up status of 192.168.1.90
        SMENKHKARE      <00> -         B <ACTIVE>
        SMENKHKARE      <03> -         B <ACTIVE>
        SMENKHKARE      <20> -         B <ACTIVE>
        ..__MSBROWSE__. <01> - <GROUP> B <ACTIVE>
        GREENGABLES     <00> - <GROUP> B <ACTIVE>
        GREENGABLES     <1d> -         B <ACTIVE>
        GREENGABLES     <1e> - <GROUP> B <ACTIVE>

        MAC Address = 00-00-00-00-00-00

..__MSBROWSE__.‘ and ‘<1d>‘ in the above output indicates that the laptop named smenkhkare is currently the Master Browser of the Workgroup named GREENGABLES. See the Microsoft TechNet article NetBIOS Over TCP/IP to interpret the output.

Now let’s look at what happens when thutmoseiii, the Windows 10 desktop connected to this home network, is powered up:

user $ smbtree
GREENGABLES
        \\AKHANATEN                     Samba 4.3.11-Ubuntu
                \\AKHANATEN\IPC$                IPC Service (Samba 4.3.11-Ubuntu)
                \\AKHANATEN\guest               guest account
                \\AKHANATEN\matthew             matthew share
                \\AKHANATEN\marilla             marilla share
                \\AKHANATEN\anne                anne share
        \\SMENKHKARE                    Samba 4.2.14
                \\SMENKHKARE\Samsung_CLX-8385ND Samsung CLX-8385ND
                \\SMENKHKARE\Canon_MP510_Printer        Canon MP510 Printer
                \\SMENKHKARE\Virtual_PDF_Printer        Virtual PDF Printer
                \\SMENKHKARE\Canon_MP560_WiFi   Canon MP560 WiFi
                \\SMENKHKARE\IPC$               IPC Service (Samba 4.2.14)
                \\SMENKHKARE\Public
                \\SMENKHKARE\anne-share
                \\SMENKHKARE\print$
                \\SMENKHKARE\netlogon           Network Logon Service
        \\TUTANKHAMUN                   Samba 4.2.11
                \\TUTANKHAMUN\Samsung_Xpress_C460FW     Samsung Xpress C460FW
                \\TUTANKHAMUN\Canon_MP560_Printer       Canon PIXMA MP560
                \\TUTANKHAMUN\Canon_MP510_Printer       Canon PIXMA MP510
                \\TUTANKHAMUN\Virtual_PDF_Printer       Virtual PDF Printer
                \\TUTANKHAMUN\IPC$              IPC Service (Samba 4.2.11)
                \\TUTANKHAMUN\Public
                \\TUTANKHAMUN\anne-share
                \\TUTANKHAMUN\print$
                \\TUTANKHAMUN\netlogon          Network Logon Service
        \\THUTMOSEIII                   Lounge Computer
HOME
        \\BTHUB5                        BT Home Hub 5.0A File Server
                \\BTHUB5\IPC$                   IPC Service (BT Home Hub 5.0A File Server)

user $ nmblookup thutmoseiii
192.168.1.74 thutmoseiii<00>
192.168.56.1 thutmoseiii<00>

user $ nmblookup -A 192.168.1.74
Looking up status of 192.168.1.74
        THUTMOSEIII     <20> -         B <ACTIVE>
        THUTMOSEIII     <00> -         B <ACTIVE>
        GREENGABLES     <00> - <GROUP> B <ACTIVE>
        GREENGABLES     <1e> - <GROUP> B <ACTIVE>

        MAC Address = AA-BB-CC-DD-EE-FF (anonymised by me)

So Linux computer smenkhkare remained the Master Browser. This is because the Windows 10 computer has its Registry subkey HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Services\Browser\Parameters\MaintainServerList set to ‘Auto‘, and also there is no subkey \HKEY_LOCAL_MACHINE\SYSTEM\CurrentControlSet\Services\Browser\Parameters\IsDomainMaster so implicitly its value is False (i.e. the computer is not a Preferred Master Browser). See Microsoft TechNet article Specifying Browser Computers for details.

By the way, notice that two IP addresses are listed for thutmoseiii. This is because thutmoseiii is connected to two network adapters: 192.168.1.74 is the IP address of thutmoseiii in the home network, and 192.168.56.1 is the IP address of the virtual network interface for the virtual computers in VirtualBox installed on thutmoseiii.

If the Samba service on smenkhkare is now stopped from the command line, Windows 10 computer thutmoseiii is elected Master Browser after more than a minute has elapsed:

user $ nmblookup -A 192.168.1.74
Looking up status of 192.168.1.74
        THUTMOSEIII     <20> -         B <ACTIVE>
        THUTMOSEIII     <00> -         B <ACTIVE>
        GREENGABLES     <00> - <GROUP> B <ACTIVE>
        GREENGABLES     <1e> - <GROUP> B <ACTIVE>
        GREENGABLES     <1d> -         B <ACTIVE>
        ..__MSBROWSE__. <01> - <GROUP> B <ACTIVE>

        MAC Address = AA-BB-CC-DD-EE-FF (anonymised by me)

If the Samba service on smenkhkare is then restarted from the command line and the Windows 10 computer is allowed to go to sleep, the laptop named smenkhkare becomes the Master Brower again as expected.

NetBIOS Commands in Windows
Now let’s look at some NetBIOS equivalent commands on the Windows 10 computer (Windows computer name: thutmoseiii).

First let’s see which remote computers thutmoseiii detects:

C:\WINDOWS\system32>nbtstat -c

VirtualBox Host-Only Network 2:
Node IpAddress: [192.168.56.1] Scope Id: []

    No names in cache

Ethernet:
Node IpAddress: [192.168.1.74] Scope Id: []

                  NetBIOS Remote Cache Name Table

        Name              Type       Host Address    Life [sec]
    ------------------------------------------------------------
    AKHANATEN      <20>  UNIQUE          192.168.1.70        381
    TUTANKHAMUN    <20>  UNIQUE          192.168.1.79        407
    SMENKHKARE     <20>  UNIQUE          192.168.1.90        416

WiFi:
Node IpAddress: [0.0.0.0] Scope Id: []

    No names in cache

Local Area Connection* 11:
Node IpAddress: [0.0.0.0] Scope Id: []

    No names in cache

Four adapters are listed in the above output: ‘VirtualBox Host-Only Network 2‘, ‘Ethernet‘, ‘WiFi‘ and ‘Local Area Connection* 11‘. Let’s look at why they are listed:

  • The first adapter listed exists because VirtualBox is installed on thutmoseiii and has a virtual network adapter to enable virtual computers to be networked together (see What Is A Oracle VM VirtualBox Host-Only Network Adapter? if you don’t know what is a VirtualBox Host-Only Network Adapter).

  • The second adapter listed is the computer’s Ethernet adapter. thutmoseiii is connected to the home network via this interface, and the above output shows that thutmoseiii has correctly detected the three other computers connected to the home network.

  • The third adapter listed is the computer’s wireless adapter. thutmoseiii also has a Wi-Fi interface, currently disabled in Windows, hence no active wireless connection is listed.

  • The fourth adapter is a ‘Microsoft Wi-Fi Direct Virtual Adapter’ according to the output of the ipconfig/all command. As the Wi-Fi interface is currently disabled in Windows, no active connection is listed here either.

Now let’s see what thutmoseiii reports about itself:

C:\WINDOWS\system32>nbtstat -n

VirtualBox Host-Only Network 2:
Node IpAddress: [192.168.56.1] Scope Id: []

                NetBIOS Local Name Table

       Name               Type         Status
    ---------------------------------------------
    THUTMOSEIII    <20>  UNIQUE      Registered
    THUTMOSEIII    <00>  UNIQUE      Registered
    GREENGABLES    <00>  GROUP       Registered
    GREENGABLES    <1E>  GROUP       Registered
    GREENGABLES    <1D>  UNIQUE      Registered
    ☺☻__MSBROWSE__☻<01>  GROUP       Registered

Ethernet:
Node IpAddress: [192.168.1.74] Scope Id: []

                NetBIOS Local Name Table

       Name               Type         Status
    ---------------------------------------------
    THUTMOSEIII    <20>  UNIQUE      Registered
    THUTMOSEIII    <00>  UNIQUE      Registered
    GREENGABLES    <00>  GROUP       Registered
    GREENGABLES    <1E>  GROUP       Registered

WiFi:
Node IpAddress: [0.0.0.0] Scope Id: []

    No names in cache

Local Area Connection* 11:
Node IpAddress: [0.0.0.0] Scope Id: []

    No names in cache

The above is correct: thutmoseiii is the Master Browser in the Windows Workgroup of VirtualBox Host-Only Network 2, but not a Master Browser in the GREENGABLES Workgroup to which thutmoseiii is connected by Ethernet cable. As the Wi-Fi interface in thutmoseiii is currently disabled, no active wireless connection is listed.

Now let’s take a look at what thutmoseiii reports about akhanaten:

C:\WINDOWS\system32>nbtstat -a akhanaten

VirtualBox Host-Only Network 2:
Node IpAddress: [192.168.56.1] Scope Id: []

    Host not found.

Ethernet:
Node IpAddress: [192.168.1.74] Scope Id: []

           NetBIOS Remote Machine Name Table

       Name               Type         Status
    ---------------------------------------------
    AKHANATEN      <00>  UNIQUE      Registered
    AKHANATEN      <03>  UNIQUE      Registered
    AKHANATEN      <20>  UNIQUE      Registered
    GREENGABLES    <00>  GROUP       Registered
    GREENGABLES    <1E>  GROUP       Registered

    MAC Address = 00-00-00-00-00-00


WiFi:
Node IpAddress: [0.0.0.0] Scope Id: []

    Host not found.

Local Area Connection* 11:
Node IpAddress: [0.0.0.0] Scope Id: []

    Host not found.

The above is also correct, as akhanaten is indeed not a Master Browser.

Now let’s have a look at what thutmoseiii reports about tutankhamun:

C:\WINDOWS\system32>nbtstat -a tutankhamun

VirtualBox Host-Only Network 2:
Node IpAddress: [192.168.56.1] Scope Id: []

    Host not found.

Ethernet:
Node IpAddress: [192.168.1.74] Scope Id: []

           NetBIOS Remote Machine Name Table

       Name               Type         Status
    ---------------------------------------------
    TUTANKHAMUN    <00>  UNIQUE      Registered
    TUTANKHAMUN    <03>  UNIQUE      Registered
    TUTANKHAMUN    <20>  UNIQUE      Registered
    GREENGABLES    <00>  GROUP       Registered
    GREENGABLES    <1E>  GROUP       Registered

    MAC Address = 00-00-00-00-00-00


WiFi:
Node IpAddress: [0.0.0.0] Scope Id: []

    Host not found.

Local Area Connection* 11:
Node IpAddress: [0.0.0.0] Scope Id: []

    Host not found.

The above is also correct, as tutankhamun is indeed not a Master Browser.

Now let’s have a look at what thutmoseiii reports about smenkhkare:

C:\WINDOWS\system32>nbtstat -a smenkhkare

VirtualBox Host-Only Network 2:
Node IpAddress: [192.168.56.1] Scope Id: []

    Host not found.

Ethernet:
Node IpAddress: [192.168.1.74] Scope Id: []

           NetBIOS Remote Machine Name Table

       Name               Type         Status
    ---------------------------------------------
    SMENKHKARE     <00>  UNIQUE      Registered
    SMENKHKARE     <03>  UNIQUE      Registered
    SMENKHKARE     <20>  UNIQUE      Registered
    ☺☻__MSBROWSE__☻<01>  GROUP       Registered
    GREENGABLES    <00>  GROUP       Registered
    GREENGABLES    <1D>  UNIQUE      Registered
    GREENGABLES    <1E>  GROUP       Registered

    MAC Address = 00-00-00-00-00-00


WiFi:
Node IpAddress: [0.0.0.0] Scope Id: []

    Host not found.

Local Area Connection* 11:
Node IpAddress: [0.0.0.0] Scope Id: []

    Host not found.

The above is also correct, as smenkhkare is indeed the Master Browser (notice the ‘☺☻__MSBROWSE__☻‘ and ‘<1D>‘).

Q.E.D.
So there you have it; Browser Elections take place and the Master Browser is any one of the Linux or Windows computers in the home network, thus enabling SMB browsing to take place. No WINS, no LDAP, no AD, no Kerberos. All SMB communication is carried out using NetBIOS over TCP/IP and Broadcast NetBIOS Name Resolution, as shown by the output of the command ‘nbtstat -r‘ on thutmoseiii:

C:\WINDOWS\system32>nbtstat -r

    NetBIOS Names Resolution and Registration Statistics
    ----------------------------------------------------

    Resolved By Broadcast     = 65
    Resolved By Name Server   = 0

    Registered By Broadcast   = 233
    Registered By Name Server = 0

    NetBIOS Names Resolved By Broadcast
---------------------------------------------
           BTHUB5         <00>
           呂啈㕂†††††䱃噅坏㌲匰⁓†
           TUTANKHAMUN    <00>
           AKHANATEN      <00>
           SMENKHKARE     <00>

I assume the line of Chinese and other characters is because of some deficiency in NBTSTAT.EXE, CMD.EXE or Windows 10 generally — despite having entered ‘CHCP 65001‘ and chosen a Unicode TrueType font in CMD.EXE — but the important point is that the statistics listed by the ‘nbtstat -r‘ command clearly show that only broadcasts are used for NetBIOS Name resolution, as promised. NetBIOS name resolution works fine in the home network and all the sharing-enabled computers in the home network can browse SMB shares on other sharing-enabled computers, whether they are running Windows, Linux, macOS, Android or iOS. I reiterate that this is for a typical home network.

Command to find Master Browsers
In Linux you can use the ‘nmblookup‘ command as follows to find out which machine in the home network is currently the Master Browser in each Workgroup:

user $ nmblookup -M -- -
192.168.1.254 __MSBROWSE__
192.168.1.90 __MSBROWSE__
192.168.56.1 __MSBROWSE__

You can see above that there are currently three Master Browsers in this home network. Let’s check the details for these three Master Browsers:

user $ nmblookup -A 192.168.1.254
Looking up status of 192.168.1.254
        BTHUB5          <00> -         B <ACTIVE>
        BTHUB5          <03> -         B <ACTIVE>
        BTHUB5          <20> -         B <ACTIVE>
        ..__MSBROWSE__. <01> - <GROUP> B <ACTIVE>
        HOME            <1d> -         B <ACTIVE>
        HOME            <1e> - <GROUP> B <ACTIVE>
        HOME            <00> - <GROUP> B <ACTIVE>

        MAC Address = 00-00-00-00-00-00

You can see above that the machine BTHUB5 (which is actually the home network’s router) is the Master Browser in the Workgroup named HOME (see earlier).

user $ nmblookup -A 192.168.1.90
Looking up status of 192.168.1.90
        SMENKHKARE      <00> -         B <ACTIVE>
        SMENKHKARE      <03> -         B <ACTIVE>
        SMENKHKARE      <20> -         B <ACTIVE>
        ..__MSBROWSE__. <01> - <GROUP> B <ACTIVE>
        GREENGABLES     <00> - <GROUP> B <ACTIVE>
        GREENGABLES     <1d> -         B <ACTIVE>
        GREENGABLES     <1e> - <GROUP> B <ACTIVE>

        MAC Address = 00-00-00-00-00-00

You can see above that computer SMENKHKARE is currently the Master Browser in the Workgroup named GREENGABLES.

user $ nmblookup -A 192.168.56.1
Looking up status of 192.168.56.1
No reply from 192.168.56.1

You can see above that the network node 192.168.56.1 is inactive, which is not surprising considering that it is a node on a VirtualBox virtual subnet on the Windows 10 computer thutmoseiii (see earlier) and VirtualBox is not running at the moment on that computer.

On a Windows machine it is not quite so easy to find out which machines are currently Master Browsers. However, on the face of it the third-party utility lanscan.exe can do it (see How to Determine the Master Browser in a Windows Workgroup):

C:\WINDOWS\system32>lanscan

LANscanner v1.67 - ScottiesTech.Info

Scanning LAN...

Scanning workgroup: HOME...

Scanning workgroup: GREENGABLES...

BTHUB5            192.168.1.254    11-11-11-11-11-11  HOME         MASTER
THUTMOSEIII       192.168.56.1     22-22-22-22-22-22  GREENGABLES  MASTER
SMENKHKARE        192.168.1.90     aa-bb-cc-dd-ee-ff  GREENGABLES  MASTER
TUTANKHAMUN       192.168.1.79     33-33-33-33-33-33  GREENGABLES
AKHANATEN         192.168.1.70     55-55-55-55-55-55  GREENGABLES

Press any key to exit...

(MAC addresses anonymised by me.)

Notice above that lanscan.exe listed the VirtualBox virtual subnet node 192.168.56.1 in Windows 10 computer thutmoseiii (see earlier) but omitted to list the node 192.168.1.74 (also thutmoseiii) in the real network. Now, in this particular case thutmoseiii on 192.168.1.74 is not a Master Browser. Nevertheless, as lanscan.exe is supposed to list all nodes, its failure to list the node 192.168.1.74 is a shortcoming.

And what happens if thutmoseiii on node 192.168.1.74 becomes a Master Browser? In that case lanscan.exe still omits the node from the list and, in addition, wrongly shows tutankhamun as a Master Browser:

C:\WINDOWS\system32>nbtstat -n

VirtualBox Host-Only Network 2:
Node IpAddress: [192.168.56.1] Scope Id: []

                NetBIOS Local Name Table

       Name               Type         Status
    ---------------------------------------------
    THUTMOSEIII    <20>  UNIQUE      Registered
    THUTMOSEIII    <00>  UNIQUE      Registered
    GREENGABLES    <00>  GROUP       Registered
    GREENGABLES    <1E>  GROUP       Registered
    GREENGABLES    <1D>  UNIQUE      Registered
    ☺☻__MSBROWSE__☻<01>  GROUP       Registered

Ethernet:
Node IpAddress: [192.168.1.74] Scope Id: []

                NetBIOS Local Name Table

       Name               Type         Status
    ---------------------------------------------
    THUTMOSEIII    <20>  UNIQUE      Registered
    THUTMOSEIII    <00>  UNIQUE      Registered
    GREENGABLES    <00>  GROUP       Registered
    GREENGABLES    <1E>  GROUP       Registered
    GREENGABLES    <1D>  UNIQUE      Registered
    ☺☻__MSBROWSE__☻<01>  GROUP       Registered

WiFi:
Node IpAddress: [0.0.0.0] Scope Id: []

    No names in cache

Local Area Connection* 11:
Node IpAddress: [0.0.0.0] Scope Id: []

    No names in cache

C:\WINDOWS\system32>nbtstat -A 192.168.1.79

VirtualBox Host-Only Network 2:
Node IpAddress: [192.168.56.1] Scope Id: []

    Host not found.

Ethernet:
Node IpAddress: [192.168.1.74] Scope Id: []

           NetBIOS Remote Machine Name Table

       Name               Type         Status
    ---------------------------------------------
    TUTANKHAMUN    <00>  UNIQUE      Registered
    TUTANKHAMUN    <03>  UNIQUE      Registered
    TUTANKHAMUN    <20>  UNIQUE      Registered
    GREENGABLES    <00>  GROUP       Registered
    GREENGABLES    <1E>  GROUP       Registered

    MAC Address = 00-00-00-00-00-00


WiFi:
Node IpAddress: [0.0.0.0] Scope Id: []

    Host not found.

Local Area Connection* 11:
Node IpAddress: [0.0.0.0] Scope Id: []

    Host not found.

C:\WINDOWS\system32>lanscan

LANscanner v1.67 - ScottiesTech.Info

Scanning LAN...

Scanning workgroup: HOME...

Scanning workgroup: GREENGABLES...

BTHUB5            192.168.1.254    11-11-11-11-11-11  HOME         MASTER
THUTMOSEIII       192.168.56.1     22-22-22-22-22-22  GREENGABLES  MASTER
TUTANKHAMUN       192.168.1.79     33-33-33-33-33-33  GREENGABLES  MASTER
SMENKHKARE        192.168.1.90     aa-bb-cc-dd-ee-ff  GREENGABLES
AKHANATEN         192.168.1.70     55-55-55-55-55-55  GREENGABLES

Press any key to exit...

(MAC addresses anonymised by me.)

Linux appears to have the edge on Windows in this respect, as the Samba command ‘nmblookup -M -- -‘ detects all the Master Browsers correctly in the above situation:

user $ nmblookup -M -- -
192.168.1.254 __MSBROWSE__
192.168.1.74 __MSBROWSE__
192.168.56.1 __MSBROWSE__

So it appears that, from a Windows computer, the only sure way to find all Master Browsers is to use the command ‘nbtstat -a <computer name>‘ to check each remote machine in the home network, plus the command ‘nbtstat -n‘ to check the Windows computer you are using.

Footnote
The ebuild of the current Gentoo Stable Branch package net-fs/samba-4.2.11 (and probably the ebuild of the Testing Branch package net-fs/samba-4.2.14 as well) is not entirely correct, as it pulls in unnecessary dependencies (see Gentoo Bug Report No. 579088 – net-fs/samba-4.x has many hard dependencies, make some optional). For example, Kerberos is not required at all if you are not using LDAP, AD, etc. and are just using NETBIOS Name Resolution by Broadcast in a Windows Workgroup (like most home users). However, the Gentoo samba ebuild forces the user to install Kerberos (either the MIT implementation app-crypt/mit-krb5 or the Heimdal implementation app-crypt/heimdal) even if you specify that Samba should be built without support for LDAP, AD, etc. This does not cause any harm, but it is unnecessary.

user $ eix -I samba
[I] net-fs/samba
     Available versions:  3.6.25^t 4.2.11 ~4.2.14 [M]~4.3.11 [M]~4.4.5 [M]~4.4.6 [M]~4.5.0 {acl addc addns ads (+)aio avahi caps (+)client cluster cups debug dmapi doc examples fam gnutls iprint ldap ldb +netapi pam quota +readline selinux +server +smbclient smbsharemodes swat syslog +system-mitkrb5 systemd test (+)winbind zeroconf ABI_MIPS="n32 n64 o32" ABI_PPC="32 64" ABI_S390="32 64" ABI_X86="32 64 x32" PYTHON_TARGETS="python2_7"}
     Installed versions:  4.2.11(19:40:03 16/09/16)(avahi client cups fam gnutls pam -acl -addc -addns -ads -aio -cluster -dmapi -iprint -ldap -quota -selinux -syslog -system-mitkrb5 -systemd -test -winbind ABI_MIPS="-n32 -n64 -o32" ABI_PPC="-32 -64" ABI_S390="-32 -64" ABI_X86="64 -32 -x32" PYTHON_TARGETS="python2_7")
     Homepage:            http://www.samba.org/
     Description:         Samba Suite Version 4

If you are a Gentoo Linux user, you can merge the package net-fs/samba with the same USE flags shown above (obviously change “-systemd” to “systemd” if you use systemd instead of OpenRC), and use the laptops’ smb.conf files shown in this post as templates, and you will be able to share files and printers using Samba and NetBIOS name resolution. Don’t forget to use pdbedit to define the Samba users, and don’t forget to stop and disable winbindd if it is already installed.

Further reading

ADDENDUM (October 30, 2016): You probably already use the Public folder in Windows. If not, you can find a brief explanation in the article Simple Questions: What is the Public Folder & How to Use it?. There are a number of default sub-folders in C:\Users\Public\ on a Windows machine. There are some differences depending on the version of Windows, but in Windows 10 (Anniversary Update) these sub-folders are named:

C:\Public\Libraries
C:\Public\Public Account Pictures
C:\Public\Public Desktop
C:\Public\Public Documents
C:\Public\Public Downloads
C:\Public\Public Music
C:\Public\Public Pictures
C:\Public\Public Videos

These predefined sub-folders are not ordinary folders, and I have noticed a surmountable minor limitation when accessing them from a Linux machine using Samba, as explained below.

If I enable Public Folder Sharing on a Windows machine (‘Turn on sharing so that anyone with network access can read and write files in the Public folders’) and configure the security permissions of the Public folder for Everyone, from another Windows machine in the Workgroup I can copy files to the first machine’s Public folder and default sub-folders. From a Linux machine in the Workgroup I can copy files to the Public folder on Windows machines in the Workgroup but I cannot copy files to the default sub-folders (the Dolphin file manager displays the error message ‘Access denied. Could not write to .‘). However, this is not a big deal because I can copy files into the Public folder itself and into manually created sub-folders in the Public folder.

Another look at beeps in Linux

Following my previous post I experimented further with the Linux Kernel configuration options for event beeps (sometimes called ‘system beeps’), and I now have a better understanding of how the Kernel options interact (on one of my laptops, at least).

The sound card in my Clevo W230SS laptop has a VIA VT1802S audio codec chip. I looked at the audio circuit schematic in the service manual; one of the digital input pins on the VT1802S is labelled ‘PCBEEP’, and one of its analogue output pins is labelled ‘PCBEEP’ and is connected to the laptop’s speaker circuit. So there is no PC Speaker in this laptop and it emulates the PC Speaker via the laptop’s sound card, as mentioned in my previous post.

Before I describe my latest results, there are a couple of influencing factors I forgot to mention in my previous post:

  • In some computers the BIOS Menu has one or more options for enabling/disabling beeps. The BIOS menu of my Clevo laptop does not have an option to enable/disable all beeps from the (emulated) PC Speaker, but it does have a couple of options to enable/disable ‘Power On Boot Beep’ and ‘Battery Low Alarm Beep’ (I have disabled them both). Anyway, if you are still not getting beeps after trying everything else, be sure to check the BIOS menu just in case it has an option to enable/disable the PC Speaker.

  • Make sure that bell-style is not set to ‘none‘ (you could set it to ‘audible‘ if you wanted to be sure):

    root # grep bell /etc/inputrc
    # do not bell on tab-completion
    #set bell-style none

The Kernel configuration was initially as shown below. With this configuration no beeps were emitted in a VT (Virtual Terminal) or in an X Windows terminal. As explained in my previous post, I therefore configured the XKB Event Daemon to play an audio file (bell.oga) whenever X Windows detects a BEL character (ASCII 007) or Backspace key (ASCII 008).

root # grep PCSP /usr/src/linux/.config
CONFIG_HAVE_PCSPKR_PLATFORM=y
CONFIG_PCSPKR_PLATFORM=y
# CONFIG_INPUT_PCSPKR is not set
# CONFIG_SND_PCSP is not set
root # grep BEEP /usr/src/linux/.config
CONFIG_SND_HDA_INPUT_BEEP=y
CONFIG_SND_HDA_INPUT_BEEP_MODE=1

Then I rebuilt the Kernel with CONFIG_INPUT_PCSPKR=M and CONFIG_SND_PCSP=M:

root # cd /usr/src/linux
root # mount /dev/sda1 /boot
root # make menuconfig
root # make && make modules_install
root # make install
root # grep PCSP /usr/src/linux/.config
CONFIG_HAVE_PCSPKR_PLATFORM=y
CONFIG_PCSPKR_PLATFORM=y
CONFIG_INPUT_PCSPKR=m
CONFIG_SND_PCSP=m
root # grep BEEP /usr/src/linux/.config
CONFIG_SND_HDA_INPUT_BEEP=y
CONFIG_SND_HDA_INPUT_BEEP_MODE=1

Then I created the file /etc/modprobe.d/blacklist.conf in order to blacklist the modules pcspkr and snd-pcsp so that only I could load them after boot:

root # cat /etc/modprobe.d/blacklist.conf
blacklist pcspkr
blacklist snd-pcsp

Then I added the line ‘options snd-pcsp index=2‘ to the file /etc/modprobe.d/alsa.conf so that the virtual sound card pcsp would not become the default sound card:

root # tail /etc/modprobe.d/alsa.conf
alias /dev/midi snd-seq-oss

# Set this to the correct number of cards.
options snd cards_limit=1

# See https://bugs.launchpad.net/ubuntu/+source/alsa-driver/+bug/1313904
options snd-hda-intel patch=,clevo-hda-patch

# See Kernel Help text for CONFIG_SND_PCSP
options snd-pcsp index=2

Then I rebooted and checked that neither module was loaded:

root # lsmod | grep pcsp
root # echo -e '\a'

root #

As neither module was loaded, the situation was the same as before: a) no beep in a VT; b) no beep in Konsole/Yakuake (I will ignore KDE terminal programs anyway because of KDE bug report no. 177861);* c) the same bell.oga beep in xterm due to my use of xkbevd; d) no changes in ALSA Mixer.

* Regarding Konsole and Yakuake, see my update of October 9, 2016 at the bottom of this post.

Then I loaded the module pcspkr:

root # modprobe pcspkr
root # lsmod | grep pcsp
pcspkr                  1875  0
root # echo -e '\a'

root #

There were no changes in ALSA Mixer. But now the BEL character and Backspace in a VT did result in a beep (I’ll call this a ‘pcbeep’ to distinguish it from the different-sounding beep produced using bell.oga). There was the usual bell.oga beep in xterm due to my use of xkbevd. If I stopped xkbevd, there was no pcbeep in X Windows from the shell commands shown in my previous post, although the following commands from any terminal in X Windows (even Konsole/Yakuake) did emit a pcbeep:

user $ sudo sh -c "echo -e '\a' > /dev/console"

user $ sudo sh -c "tput bel > /dev/console"

root # echo -e '\a' > /dev/console

root # tput bel > /dev/console

Then I unloaded the module pcspkr and loaded the module snd-pcsp:

root # modprobe -r pcspkr
root # modprobe snd-pcsp
root # lsmod | grep pcsp
snd_pcsp                7918  1
root # echo -e '\a'

root #

ALSA Mixer showed a new sound card named ‘pcsp‘ (Sound Card 2) with three channels: ‘Master’, ‘Beep’ and ‘BaseFRQ’. I could mute/unmute ‘Beep’ by pressing ‘M’ on the keyboard as usual, and I could toggle ‘BaseFRQ’ between two values:18643 and 37286. The BEL character and Backspace in a VT resulted in a pcbeep. There was the usual bell.oga beep in xterm due to my use of xkbevd. If I stopped xkbevd, there was no pcbeep in X Windows from the shell commands shown in my previous post, although the following commands from any terminal in X Windows (even Konsole/Yakuake) did emit a pcbeep:

user $ sudo sh -c "echo -e '\a' > /dev/console"

user $ sudo sh -c "tput bel > /dev/console"

root # echo -e '\a' > /dev/console

root # tput bel > /dev/console

Muting ‘Beep’ in ALSA Mixer did not mute the bell.oga beeps in X Windows, but it did mute the pcbeeps in the VTs.

Unlike the situation with the pcspkr module, occasionally there were brief low-volume crackles and pops from the laptop’s speakers.

So both drivers worked, but pcspkr performed better, although it could not be muted via ALSA Mixer. My recommendation to use pcspkr rather than snd-pcsp still stands.

Unlike pcspkr, I had to force the unloading of snd-pcsp:

root # modprobe -r snd-pcsp
modprobe: FATAL: Module snd_pcsp is in use.
root # rmmod -f snd_pcsp
root #

I then removed the Kernel’s ‘digital beep’ interface for the Intel HDA driver by rebuilding the Kernel with CONFIG_SND_HDA_INPUT_BEEP=N:

root # cd /usr/src/linux
root # mount /dev/sda1 /boot
root # make menuconfig
root # make && make modules_install
root # make install
root # grep PCSP /usr/src/linux/.config
CONFIG_HAVE_PCSPKR_PLATFORM=y
CONFIG_PCSPKR_PLATFORM=y
CONFIG_INPUT_PCSPKR=m
CONFIG_SND_PCSP=m
root # grep BEEP /usr/src/linux/.config
# CONFIG_SND_HDA_INPUT_BEEP is not set
root #

After I rebooted, the behaviour was exactly the same as for CONFIG_SND_HDA_INPUT_BEEP=Y and CONFIG_SND_HDA_INPUT_BEEP_MODE=1.

So, there you have it. I believe my previous post was essentially correct regarding the functional design of the Kernel options. If you have a computer without a PC Speaker but it emulates one via the computer’s sound card, you have to set either CONFIG_INPUT_PCSPKR or CONFIG_SND_PCSP to get a beep in a VT, not set just CONFIG_SND_HDA_INPUT_BEEP and CONFIG_SND_HDA_INPUT_BEEP_MODE. However, even when my laptop emits beeps in a VT from the (emulated) PC Speaker, no beeps from the (emulated) PC Speaker are emitted in X Windows unless the user is the root user and the output is redirected to /dev/console. So, if you want to emit beeps in X Windows it is still better in my opinion to use xkbevd to play an audio file of a beep, as described in my previous post.

Update (October 9, 2016): Regarding KDE’s terminal applications emitting beeps, I am currently using KDE Plasma 5.7.5 and have been able to configure Konsole and Yakuake to play an audio file of a beep (as opposed to emitting a pcbeep) as follows:

  • In Konsole, click on ‘Settings’ > ‘Configure Notifications…’, select ‘Bell in Visible Session’ and ensure ‘Play a sound’ is ticked and a file is specified there (I specify /usr/share/sounds/freedesktop/stereo/bell.oga). If you wish, do the same for ‘Bell in Non-Visible Session’.
  • For Yakuake, press F12 to display the Yakuake window, click on the ‘Open Menu’ icon, select ‘Configure Notifications…’, select ‘Bell in Visible Session’ and ensure ‘Play a sound’ is ticked and a file is specified there (I specify /usr/share/sounds/freedesktop/stereo/bell.oga). If you wish, do the same for ‘Bell in Non-Visible Session’.

To beep, or not to beep, that is the question

Introduction

If your computer running Linux has the necessary hardware and is configured appropriately, applications and shell scripts can trigger a beep to signal an event such as an invalid keyboard entry, shutdown initiation, and so on. To check the current situation with your computer, enter the command shown below. Try it first in a Linux VT (virtual terminal) and then in a terminal window in X Windows. Do you hear a beep in each case?

user $ echo -e '\a'

The above command outputs the BEL character (ASCII code 007).

An alternative to the above command is:

user $ echo -e '\007'

Another command that should produce a beep is:

user $ tput bel

The tput utility is part of the ncurses package.

If you install the package app-misc/beep you can also use the ‘beep’ command (enter the command ‘man beep‘ to see its options):

user $ beep

Although you can enter the above-mentioned commands on the command line, they are intended to be used in shell scripts to notify the user about something.

There are thousands of posts on the Web regarding beeps in Linux, the majority of them concerned with disabling beeps because many people find them annoying. Historically, such beeps were emitted by the so-called ‘PC speaker‘. Note that the PC Speaker is not the same as the speakers connected to the sound card in your computer; the term refers to a small internal loudspeaker (moving-coil or piezoelectric) wired directly to the motherboard and intended solely to emit beeps to notify the user about something. Many modern computers, especially laptops, do not have a PC Speaker and either emulate one via the sound card or do nothing at all.

The reason people sometimes use the terms ‘bell’ and ‘ring’ instead of ‘beep’ is because old teletypwriters and teleprinters actually had an electromechanical bell which would ring when a certain dedicated character was received. I use the terms ‘beep’ and ‘bell’ interchangeably, although I prefer to use the term ‘beep’ when talking about audible notifications by computers.

I was motivated to write this post after helping a Gentoo Linux user to get his laptop to produce beeps (see the Gentoo Linux Forums thread ‘i want to beep [solved]‘). Producing a beep in Linux turns out to be more complicated than you would expect, and I’m not sure I fully understand the functional design of the applicable configuration options in the Kernel, nor their relevance (if any) to the X Windows server’s bell. Now, on the face of it the functionality of the applicable Kernel configuration options appears straightforward, but that is not the case in practice. Anyway, let’s look at how I believe a beep can be achieved (and disabled) in Linux…

PC Speaker drivers

Four Kernel options relate directly to a PC Speaker:

CONFIG_HAVE_PCSPKR_PLATFORM

If this is not set in the Kernel then CONFIG_PCSPKR_PLATFORM cannot be enabled.

CONFIG_PCSPKR_PLATFORM

Enable PC-Speaker support

This option allows to disable the internal PC-Speaker
support, saving some memory.

CONFIG_INPUT_PCSPKR

PC Speaker support

Say Y here if you want the standard PC Speaker to be used for
bells and whistles.

If unsure, say Y.

To compile this driver as a module, choose M here: the
module will be called pcspkr.

CONFIG_SND_PCSP

PC-Speaker support (READ HELP!)

If you don’t have a sound card in your computer, you can include a
driver for the PC speaker which allows it to act like a primitive
sound card.
This driver also replaces the pcspkr driver for beeps.

You can compile this as a module which will be called snd-pcsp.

WARNING: if you already have a soundcard, enabling this
driver may lead to a problem. Namely, it may get loaded
before the other sound driver of yours, making the
pc-speaker a default sound device. Which is likely not
what you want. To make this driver play nicely with other
sound driver, you can add this into your /etc/modprobe.conf:
options snd-pcsp index=2

You don’t need this driver if you only want your pc-speaker to beep.
You don’t need this driver if you have a tablet piezo beeper
in your PC instead of the real speaker.

Say N if you have a sound card.
Say M if you don’t.
Say Y only if you really know what you do.

If your computer does have a PC Speaker, you would use either CONFIG_INPUT_PCSPKR or CONFIG_SND_PCSP, but not both. When configuring the Kernel you can specify ‘M’ to build the driver as an external module, in which case you can decide in userspace whether or not to load it. Or you can specify ‘Y’ to build the driver into the Kernel (do not specify both as ‘Y’ simultaneously, though).

If your computer does have a PC Speaker, an advantage of using CONFIG_SND_PCSP instead of CONFIG_INPUT_PCSPKR is that the former adds a virtual sound card named ‘pcsp’ with a channel (without volume control) named ‘Beep’, and you should be able to mute it via ALSA Mixer.

If you have a computer that has a sound card but does not have a PC Speaker (a laptop’s internal speakers are connected to a sound card, not a PC Speaker), the above two drivers do not really apply. I have always disabled them both in the Kernel, as my laptop does not have a PC Speaker.  Update (September 29, 2016): This is not always the case: if a computer uses a sound card to emulate a PC Speaker (typically laptops do this), then you do need to use one of these two drivers if you want to be able to hear event beeps in a VT — see my latest post Another look at beeps in Linux.

However, apparently for some laptops ALSA Mixer shows a channel named ‘Beep’ (with volume control) for the Intel HDA (High Definition Audio) sound card if CONFIG_INPUT_PCSPKR is set to ‘Y’ or ‘M’. I believe such laptops were designed to use their sound card to emulate a PC Speaker. I do not know whether or not the ‘digital beep’ Kernel options (see further on) are set in such cases, but Kernel bug report no. 13651 would appear to indicate that the design intention is for them to be set.

So, already things are confusing.

Of course, if your computer does have a PC Speaker and you don’t want it to emit beeps, set both CONFIG_INPUT_PCSPKR and CONFIG_INPUT_PCSP to ‘N’ in the Kernel. If either already exists as an external module and you do not wish to rebuild the Kernel, make sure the modules pcspkr and snd-pcsp are not loaded (blacklist them, for example).

Digital Beep

Now, there are two other Kernel options relating to event beeps. These are not for driving a PC Speaker, they are to enable the ALSA Intel HDA driver to emit event beeps in lieu of a PC Speaker: the so-called ‘digital beep’. In other words, these two options are intended to provide an alternative to using a PC Speaker. The two options are:

CONFIG_SND_HDA_INPUT_BEEP

Support digital beep via input layer

Say Y here to build a digital beep interface for HD-audio
driver. This interface is used to generate digital beeps.

CONFIG_SND_HDA_INPUT_BEEP_MODE

Digital beep registration mode (0=off, 1=on)

Set 0 to disable the digital beep interface for HD-audio by default.
Set 1 to always enable the digital beep interface for HD-audio by
default.

Note that the mode ‘2’ is no longer an option in newer Kernels.

So, if your installation uses the Intel HDA driver and you want your computer’s sound card to be able to emit beeps instead of a PC Speaker (which your computer may or may not have), set these two accordingly in the Kernel configuration:

user $ grep CONFIG_SND_HDA_INPUT_BEEP /usr/src/linux/.config
CONFIG_SND_HDA_INPUT_BEEP=y
CONFIG_SND_HDA_INPUT_BEEP_MODE=1

The functional design of these Kernel options is not clear, but Kernel bug report no. 13651 appears to indicate that the design intention is for CONFIG_SND_HDA_INPUT_BEEP and CONFIG_SND_HDA_INPUT_BEEP_MODE to be used in addition to either CONFIG_INPUT_PCSPKR or CONFIG_SND_PCSP, not instead of them. In other words, if your computer has a PC Speaker but you want beeps to be routed via its Intel HDA sound card instead then I believe you are expected to use either of the following two sets of options:

Option 1
CONFIG_HAVE_PCSPKR_PLATFORM=Y
CONFIG_PCSPKR_PLATFORM=Y
CONFIG_INPUT_PCSPKR=Y (or =M)
CONFIG_SND_HDA_INPUT_BEEP=Y
CONFIG_SND_HDA_INPUT_BEEP_MODE=1

Option 2
CONFIG_HAVE_PCSPKR_PLATFORM=Y
CONFIG_PCSPKR_PLATFORM=Y
CONFIG_SND_PCSP=Y (or =M)
CONFIG_SND_HDA_INPUT_BEEP=Y
CONFIG_SND_HDA_INPUT_BEEP_MODE=1

On the other hand, if your computer has a PC Speaker and your installation uses the Intel HDA driver for a sound card but you do want your computer to emit beeps from the PC Speaker, I think you would set the two options as follows in the Kernel configuration:

CONFIG_SND_HDA_INPUT_BEEP=N
CONFIG_SND_HDA_INPUT_BEEP_MODE=0

If you read the comment by ALSA developer Takashi Iwai quoted in Kernel bug report no. 13651 you’ll see that the functionality is not at all straightforward. For example, on some computers, especially laptops (which normally do not have a PC Speaker), the beep may be emitted via the sound card irrespective of whether or not you set CONFIG_SND_HDA_INPUT_BEEP.

X Windows

A beep can be emitted in X Windows, and I have seen this beep referred to as the ‘X Windows server bell’ or the ‘X Windows keyboard bell’.

Given that X Windows can emit a beep via the sound card when neither the pcspkr module nor the snd-pcsp module is loaded and CONFIG_SND_HDA_INPUT_BEEP=N and CONFIG_SND_HDA_INPUT_BEEP_MODE=0, I assume X Windows emits beeps directly to the default sound card irrespective of the settings of those Kernel options. I could be wrong, but I have not found any explanation on the Web about the underlying mechanism; the X.Org Web site FAQ ‘How can I configure the Xserver bell (xkbbell) to use the sound subsystem of my computer? (ALSA, OSS, etc.)‘ simply states:

Answer (hopefully) goes here..🙂

*shrug*.

Below is a summary of the commands to disable, enable and configure the beep in X Windows.

To disable beeps in X Windows:

user $ xset b off

To enable beeps in X Windows:

user $ xset b on

To change the volume, pitch and duration of the beeps:

user $ xset b <volume> <pitch> <duration>

For example, to set the beep volume to 25% without changing the pitch and duration:

user $ xset b 25

To return to the default settings:

user $ xset b

To view the current settings:

user $ xset q | grep bell

which displays the following (default) values in my case:

bell percent:  50        bell pitch:    400        bell duration:    100

To set the beep automatically each time X Windows starts, add the following line before the last one in the ~/.xinitrc file if you don’t use a Desktop Manager, otherwise use the Desktop Environment’s system settings GUI to run it at login:

xset b 20 400 20 &

PulseAudio

To confuse matters further, note that PulseAudio intercepts X11 beeps (see: PulseAudio Documentation – User Documentation – Modules – X Window system – module-x11-bell). Therefore, if your installation uses PulseAudio and you want the ability to emit event beeps in X Windows, you also need to configure PulseAudio so it does not ignore the beeps. This can either be done from the command line:

user $ pactl upload-sample /usr/share/sounds/freedesktop/stereo/bell.oga x11-bell
user $ pactl load-module module-x11-bell sample=x11-bell display=$DISPLAY

or you can edit /etc/pulse/default.pa and make sure the following lines are included in that file (they may already exist but are commented out):

load-sample-lazy x11-bell /usr/share/sounds/freedesktop/stereo/bell.oga
load-module module-x11-bell sample=x11-bell

On the other hand, if PulseAudio is installed and you want it to ignore event beeps in X Windows, delete or comment out the above-mentioned two lines in /etc/pulse/default.pa. You can achieve the same effect from the command line:

user $ pactl unload-module module-x11-bell

Configuring userspace to emit a ‘digital beep’

Installation of PulseAudio will have created the directory /usr/share/sounds/freedesktop/ and sub-directories containing various Ogg Vorbis audio files, including the ‘digital beep’ file bell.oga. If your installation does not have PulseAudio installed, you can obtain the same file /usr/share/sounds/freedesktop/stereo/bell.oga by installing the package x11-themes/sound-theme-freedesktop instead. You can configure your installation to use this file to emit a ‘digital beep’ in X Windows (but not in a VT) by using the XKB (X Windows keyboard extension) event daemon as explained in a post on the superuser Web site. That post relates to Ubuntu, but the basic principle applies whatever the Linux distribution.

Now, in my case I am using KDE Plasma 5 in Gentoo Linux, and I cannot hear any beep/bell in Konsole and Yakuake. I came across KDE bug report no. 177861 that has been outstanding since 2008, which indicated that KDE’s terminal applications will not emit beeps even if you do have a PC Speaker and your Kernel has been correctly configured to use it, or even if you have configured your installation to use a ‘digital beep’. You may have better luck with a different Desktop Environment but in KDE you will have to use a non-KDE X Windows terminal application if you want to hear beeps produced by shell scripts.

Update (October 9, 2016): Regarding KDE’s terminal applications emitting beeps, I am currently using KDE Plasma 5.7.5 and have been able to configure Konsole and Yakuake to emit a ‘digital beep’ as follows:

  • In Konsole, click on ‘Settings’ > ‘Configure Notifications…’, select ‘Bell in Visible Session’ and ensure ‘Play a sound’ is ticked and a file is specified there (I specify /usr/share/sounds/freedesktop/stereo/bell.oga). If you wish, do the same for ‘Bell in Non-Visible Session’.
  • For Yakuake, press F12 to display the Yakuake window, click on the ‘Open Menu’ icon, select ‘Configure Notifications…’, select ‘Bell in Visible Session’ and ensure ‘Play a sound’ is ticked and a file is specified there (I specify /usr/share/sounds/freedesktop/stereo/bell.oga). If you wish, do the same for ‘Bell in Non-Visible Session’.

Below I explain how I implemented a ‘digital beep’ in KDE Plasma 5.

First I installed the XKB event daemon:

root # emerge xkbevd

The package vorbis-tools was already installed, otherwise I would have installed that too in order to install an audio player for Ogg Vorbis audio files:

root # emerge vorbis-tools

PulseAudio was also already installed, and hence an appropriate audio file for a beep already existed. Had I not previously installed PulseAudio I would have installed the following package to get an appropriate Ogg Vorbis audio file:

root # emerge sound-theme-freedesktop

I created the file /home/fitzcarraldo/.config/autostart/xkbevd.desktop containing the following:

[Desktop Entry]
Comment[en_GB]=Software terminal bell
Comment=Software terminal bell
Exec=xkbevd -bg
GenericName[en_GB]=XKB Event Daemon
GenericName=XKB Event Daemon
Icon=system-run
MimeType=
Name[en_GB]=XKB Event Daemon
Name=XKB Event Daemon
Path=
StartupNotify=true
Terminal=false
TerminalOptions=
Type=Application
X-DBUS-ServiceName=
X-DBUS-StartupType=none
X-KDE-SubstituteUID=false
X-KDE-Username=fitzcarraldo

and I changed its permissions:

user $ chmod 755 /home/fitzcarraldo/.config/autostart/xkbevd.desktop

I created the file /home/fitzcarraldo/.xkb/xkbevd.cf containing the following:

soundDirectory="/usr/share/sounds/"
soundCmd="ogg123 -q"

Bell() "freedesktop/stereo/bell.oga"

If the file /usr/share/sounds/freedesktop/stereo/bell.oga does not exist in your installation then you can copy any suitable audio file of your choice into the directory /usr/share/sounds/ or use one of the existing audio files in that directory, and specify its filename in xkbevd.cf. For example:

soundDirectory="/usr/share/sounds/"
soundCmd="aplay -q"

Bell() "beep.wav"

Notice that the choice of audio player is up to you. In the first example of xkbevd.cf I specified the ogg123 player, whereas in the second example I specified the aplay player.

The aforementioned bug in KDE Konsole and Yakuake prevented me from testing the use of the XKB event daemon, so I installed a non-KDE X Windows terminal application to see if the ‘digital beep’ would work in that:

root # emerge xterm

The command echo -e '\a' generates a beep in xterm. So the ‘digital beep’ approach does work, albeit use of the XKB event daemon means you are limited to using it in X Windows. To reiterate, as the XKB event daemon is for X Windows, no ‘digital beep’ is generated if you enter a beep command outside of X Windows (e.g. in a VT).

By the way, I’m currently using Gentoo Stable Branch and hence Version 5.6.5 of KDE Plasma, and there is another KDE bug to complicate matters further: ‘System Settings’ > ‘Autostart’ > ‘Add Program…’ does not save all the entries I make via the GUI to the .desktop file, and does not set the file permissions correctly either. I don’t know if that is an upstream bug or a bug in the Gentoo implementation of Plasma 5.6.5. Anyway, that is why I manually created xkbevd.desktop and manually set the permissions, rather than using System Settings.

Instead of launching the XKB event daemon by using a .desktop file in ~/.config/autostart/, if you don’t use a Desktop Manager you could launch it by adding the command in the file ~/.xinitrc.

Summary

All the following factors govern whether or not your computer will issue a beep for the BEL character:

  • the specific hardware and firmware in your computer;
  • CONFIG_HAVE_PCSPKR_PLATFORM;
  • CONFIG_PCSPKR_PLATFORM;
  • CONFIG_INPUT_PCSPKR;
  • CONFIG_SND_PCSP;
  • CONFIG_SND_HDA_INPUT_BEEP;
  • CONFIG_SND_HDA_INPUT_BEEP_MODE;
  • X Windows settings;
  • PulseAudio configuration (if installed);
  • a bug in KDE’s terminal applications (if installed).

A. If you are hearing event beeps but don’t want them:

  • Preferably, set CONFIG_HAVE_PCSPKR_PLATFORM and CONFIG_PCSPKR_PLATFORM both to ‘N’.
  • Either set both CONFIG_INPUT_PCSPKR and CONFIG_SND_PCSP to ‘N’ in your Kernel, or, if either driver exists as a module (pcspkr and snd-pcsp, respectively), blacklist it.
  • Make sure CONFIG_SND_HDA_INPUT_BEEP is set to ‘N’.
  • Make sure the X Windows bell is turned off.
  • If you also have PulseAudio installed, make sure the PulseAudio module module-x11-bell is not loaded (also check /etc/pulse/default.pa to see if it has been enabled by default).

B. If you are not hearing event beeps but you do want to hear them:

1. If you are sure your computer has a PC Speaker:

  • Make sure CONFIG_HAVE_PCSPKR_PLATFORM and CONFIG_PCSPKR_PLATFORM are set to ‘Y’.
  • Either set CONFIG_INPUT_PCSPKR to ‘M’ and CONFIG_SND_PCSP to ‘N’ in your Kernel, or, if the module snd-pcsp already exists, blacklist it.
  • Make sure the module pcspkr exists and is not blacklisted.
  • Make sure the module pcspkr is loaded after the module snd-hda-intel.
  • Make sure CONFIG_SND_HDA_INPUT_BEEP is set to ‘N’.
  • Make sure the X Windows bell is turned on and the volume is turned up.
  • If you have PulseAudio installed, make sure the PulseAudio module module-x11-bell is loaded (check /etc/pulse/default.pa to ensure it includes the applicable lines, or issue the two commands listed earlier).
  • If you use KDE, use a non-KDE terminal application until KDE bug report no. 177861 is fixed.
  • If, after doing all the above, you still do not hear a beep in X Windows, follow the procedure in the section above titled Configuring userspace to emit a ‘digital beep’.

Above I have recommended using pcspkr. However, an advantage of using snd-pcsp instead is that it adds a virtual sound card with a channel named ‘Beep’ and you should be able to mute that channel via ALSA Mixer as you wish. Therefore, if you do opt to use the module snd-pcsp instead of pcspkr then make sure you specify the module option (or Kernel Quirk if you built the driver into the Kernel) described in the Kernel Help text quoted earlier, so that pcsp does not become the default sound card instead of the Intel HDA sound card.

2. If your computer does not have a PC Speaker:

  • Preferably, set CONFIG_HAVE_PCSPKR_PLATFORM and CONFIG_PCSPKR_PLATFORM both to ‘N’. *
  • If you leave CONFIG_HAVE_PCSPKR_PLATFORM and CONFIG_PCSPKR_PLATFORM both set to ‘Y’, either set CONFIG_INPUT_PCSPKR and CONFIG_SND_PCSP both to ‘N’, or, if either module already exists, blacklist it. *
  • Make sure CONFIG_SND_HDA_INPUT_BEEP is set to ‘Y’ and CONFIG_SND_HDA_INPUT_BEEP_MODE is set to ‘1’ (I’m not sure this step is required for all computers).
  • Make sure the X Windows bell is turned on and its volume is turned up.
  • If you have PulseAudio installed, make sure the PulseAudio module module-x11-bell is loaded.
  • Use the XKB Event Daemon method to play an audio file (‘digital beep’) when the BEL character is detected in X Windows.
  • If you use KDE, use a non-KDE terminal application until KDE bug report no. 177861 is fixed.
    Update (October 9, 2016): Regarding KDE’s terminal applications emitting beeps, I am currently using KDE Plasma 5.7.5 and have been able to configure Konsole and Yakuake to emit a ‘digital beep’ — see my update in the section titled Configuring userspace to emit a ‘digital beep’.

    * If your computer’s hardware and firmware have been designed to emulate a PC Speaker via a sound card, you may find that you can use the pcspkr (or snd-pcsp) driver to generate beeps in a VT. As the saying goes, your mileage may vary.

    And Finally

    If you know precisely how all these Kernel options are supposed to interact, do comment. Or if you know the relationship, if any, between the X Windows beep (a.k.a. ‘bell’) and these Kernel options, please also comment.

    Update (September 29, 2016): See my latest post Another look at beeps in Linux for the results of some experiments with these Kernel options on my laptop, giving more insight into how to configure them and how they work.

How to enable a Windows application in WINE to access a Samba share on a NAS

I recently installed the Windows application PDF-XChange Editor under WINE in Gentoo Linux on one of my laptops. The application works fine but it could not detect the SMB/CIFS (Samba) share folder on my NAS. When I clicked on ‘File‘ > ‘Open...‘ in the application, the left pane of the ‘Open Files‘ dialogue window displayed the following options:

  Favourites
– Desktop
  + My Computer
  + My Documents
    Trash
  + /

If I clicked on ‘My Computer‘, the right pane of the dialogue window then displayed the following options:

Control Panel
(C:)
(D:)
(E:)
(F:)
(G:)
(Z:)

None of the entries in either pane enabled me to get to the Samba shares on my NAS. Anyway, it turned out to be relatively easy to configure the installation on my laptop to enable the Windows application to access the Samba shared folder on the NAS, and the basic procedure was as follows:

  1. Create a mountpoint.
  2. In the directory $WINEPREFIX/dosdevices/ create a symbolic link to the mountpoint.
  3. Mount the network share on the mountpoint.

Let’s look in detail at the procedure…

My Clevo W230SS laptop running Gentoo Linux Stable Branch amd64 currently has KDE Plasma 5.6.5 and WINE 1.9.18 installed. I had used a WINE prefix of ~/.wine-pdfxve6 to install the Windows application in the fitzcarraldo user account. Let us say that the hostname of my Linux NAS is ‘bsfnas1‘, the name of the Samba shared folder on the NAS is ‘brianfolder‘, the Samba username for that shared folder on the NAS is ‘brian‘ and the Samba share password on the NAS is ‘enricocaruso‘.

First I checked which drive letters were already being used by WINE:

$ ls -la ~/.wine-pdfxve6/dosdevices/
total 8
drwxr-xr-x 2 fitzcarraldo fitzcarraldo 4096 Sep 16 23:18 .
drwxr-xr-x 4 fitzcarraldo fitzcarraldo 4096 Sep 17 04:03 ..
lrwxrwxrwx 1 fitzcarraldo fitzcarraldo   10 Sep 16 23:18 c: -> ../drive_c
lrwxrwxrwx 1 fitzcarraldo fitzcarraldo    9 Sep 16 23:18 d:: -> /dev/sdb1
lrwxrwxrwx 1 fitzcarraldo fitzcarraldo    8 Sep 16 23:18 e:: -> /dev/sdc
lrwxrwxrwx 1 fitzcarraldo fitzcarraldo    9 Sep 16 23:18 f:: -> /dev/sdc1
lrwxrwxrwx 1 fitzcarraldo fitzcarraldo    8 Sep 16 23:18 g:: -> /dev/sdb
lrwxrwxrwx 1 fitzcarraldo fitzcarraldo    1 Sep 16 23:18 z: -> /

As no Windows Y: drive was listed, I decided to use that drive letter for my network Samba share as shown in the steps below.

I created a mountpoint for the share:

$ sudo mkdir -p /media/bsfnas1/brianfolder

Then I created the symlink:

$ ln -s /media/bsfnas1/brianfolder ~/.wine-pdfxve6/dosdevices/y:
$ ls -la ~/.wine-pdfxve6/dosdevices/
total 8
drwxr-xr-x 2 fitzcarraldo fitzcarraldo 4096 Sep 17 15:38 .
drwxr-xr-x 4 fitzcarraldo fitzcarraldo 4096 Sep 17 15:39 ..
lrwxrwxrwx 1 fitzcarraldo fitzcarraldo   10 Sep 16 23:18 c: -> ../drive_c
lrwxrwxrwx 1 fitzcarraldo fitzcarraldo    9 Sep 16 23:18 d:: -> /dev/sdb1
lrwxrwxrwx 1 fitzcarraldo fitzcarraldo    8 Sep 16 23:18 e:: -> /dev/sdc
lrwxrwxrwx 1 fitzcarraldo fitzcarraldo    9 Sep 16 23:18 f:: -> /dev/sdc1
lrwxrwxrwx 1 fitzcarraldo fitzcarraldo    8 Sep 16 23:18 g:: -> /dev/sdb
lrwxrwxrwx 1 fitzcarraldo fitzcarraldo   11 Sep 17 15:37 y: -> /media/bsfnas1/brianfolder
lrwxrwxrwx 1 fitzcarraldo fitzcarraldo    1 Sep 16 23:18 z: -> /

Finally, I mounted the network share onto the symlink:

$ sudo mount.cifs //bsfnas1/brianfolder/ -o user=brian,pass=enricocaruso ~/.wine-pdfxve6/dosdevices/y:

As before, I see the following when I click on ‘File‘ > ‘Open...‘ in the Windows application running under WINE:

  Favourites
– Desktop
  + My Computer
  + My Documents
    Trash
  + /

If I click on ‘My Computer‘ in the ‘Open File‘ dialogue window, the following items are displayed in the right pane of the window:

Control Panel
(C:)
(D:)
(E:)
(F:)
(G:)
(Y:)
(Z:)

and I can select the ‘(Y:)‘ and browse the contents of the shared folder brianfolder on the NAS drive.

Although I found it was unnecessary to do it for PDF-XChange Editor, apparently some Windows applications require the use of Windows UNC syntax, so I also did the following:

$ mkdir -p ~/.wine-pdfxve6/dosdevices/unc/bsfnas1
$ ln -s /media/bsfnas1/brianfolder ~/.wine-pdfxve6/dosdevices/unc/bsfnas1/brianfolder

If I wanted to unmount the Samba share explicitly, rather than leaving it to be unmounted automatically when I shutdown the laptop, I would enter the following command:

$ sudo umount ~/.wine-pdfxve6/dosdevices/y\:/

Then the Windows application on my laptop would no longer be able to browse the unmounted network share:

$ ls ~/.wine-pdfxve6/dosdevices/
c:  d::  e::  f::  g::  unc  y:  z:
$ ls -la /media/bsfnas1/brianfolder
total 8
drwxr-xr-x 2 root root 4096 Sep 17 15:35 .
drwxr-xr-x 4 root root 4096 Sep 17 15:35 ..
$

You may be wondering why I did not add an entry in the file /etc/fstab on my laptop, to mount the Samba share automatically when I boot the laptop. The reason I didn’t is because I often use the laptop away from home and the NAS on my home network is then inaccessible in any case. However, to save myself the hassle of having to enter the mount command manually when I am at home and want to use the Windows application to open a file that is in the NAS shared folder, I created two Desktop Configuration files named mount_bsfnas1_brianfolder_share.desktop and umount_bsfnas1_brianfolder_share.desktop with nice icons in my ~/Desktop directory on the laptop:

[Desktop Entry]
Comment[en_GB]=Mount bsfnas1 brianfolder share for PDF-XChange Editor
Comment=Mount bsfnas1 brianfolder share for PDF-XChange Editor
Exec=sh /home/fitzcarraldo/mount_bsfnas1_brianfolder_share.sh
GenericName[en_GB]=Mount bsfnas1 brianfolder share for PDF-XChange Editor
GenericName=Mount bsfnas1 brianfolder share for PDF-XChange Editor
Icon=media-mount
MimeType=
Name[en_GB]=mount_bsfnas1_brianfolder_share
Name=mount_bsfnas1_brianfolder_share
Path=
StartupNotify=true
Terminal=true
TerminalOptions=\s--noclose
Type=Application
X-DBUS-ServiceName=
X-DBUS-StartupType=none
X-KDE-SubstituteUID=false
X-KDE-Username=fitzcarraldo

[Desktop Entry]
Comment[en_GB]=Unmount bsfnas1 brianfolder share for PDF-XChange Editor
Comment=Unmount bsfnas1 brianfolder share for PDF-XChange Editor
Exec=sh /home/fitzcarraldo/umount_bsfnas1_brianfolder_share.sh
GenericName[en_GB]=Unmount bsfnas1 brianfolder share for PDF-XChange Editor
GenericName=Unmount bsfnas1 brianfolder share for PDF-XChange Editor
Icon=media-eject
MimeType=
Name[en_GB]=umount_bsfnas1_brianfolder_share
Name=umount_bsfnas1_brianfolder_share
Path=
StartupNotify=true
Terminal=true
TerminalOptions=\s--noclose
Type=Application
X-DBUS-ServiceName=
X-DBUS-StartupType=none
X-KDE-SubstituteUID=false
X-KDE-Username=fitzcarraldo

and the Bash scripts mount_bsfnas1_brianfolder_share.sh and umount_bsfnas1_brianfolder_share.sh launched by the above two Desktop Configuration files are, respectively:

#!/bin/bash
echo "This will mount the Samba share folder brianfolder on the bsfnas1 machine."
echo
echo "Enter your Linux account password below..."
echo
sudo mount.cifs //bsfnas1/brianfolder/ -o user=brian,pass=enricocaruso ~/.wine-pdfxve6/dosdevices/y:
echo
if grep -q "/media/bsfnas1/brianfolder" /proc/mounts; then
  echo "Samba share //bsfnas1/brianfolder is mounted."
else
  echo "Samba share //bsfnas1/brianfolder is not mounted."
fi
echo
echo "You may now close this window."

#!/bin/bash
echo "This will unmount the Samba share folder brianfolder on the bsfnas1 machine."
echo
echo "Enter your Linux account password below..."
echo
sudo umount ~/.wine-pdfxve6/dosdevices/y:
echo
if grep -q "/media/bsfnas1/brianfolder" /proc/mounts; then
  echo "Samba share //bsfnas1/brianfolder is mounted."
else
  echo "Samba share //bsfnas1/brianfolder is not mounted."
fi
echo
echo "You may now close this window."

Don’t forget to make the two shell scripts executable:

$ chmod +x /home/fitzcarraldo/mount_bsfnas1_brianfolder_share.sh
$ chmod +x /home/fitzcarraldo/umount_bsfnas1_brianfolder_share.sh

If I was doing this on a desktop PC instead of a laptop, instead of creating the above-mentioned .desktop files and Bash scripts I would have added the following line in the file /etc/fstab to mount the NAS Samba shared folder automatically at boot:

//bsfnas1/brianfolder  /media/bsfnas1/brianfolder  cifs  rw,iocharset=utf8,user=brian,pass=enricocaruso  0   0

It works (I’ve tried it).

Further reading
WineHQ Forums – Mapped network drive in wine.
Estendendo suporte a UNC no Wine.

Eliminating the loud hum from powered speakers connected to my laptop

My external powered speakers emit a loud, annoying hum if I plug them into the headphones socket of my Clevo W230SS laptop. The hum stops if I unplug the laptop’s mains charger, so the problem is due to an earth loop (a.k.a. ‘ground loop’). The charger’s recessed socket for connecting its mains lead has three prongs (IEC 60320 C6), i.e. the charger is not double-insulated. The recessed socket on a double-insulated mains charger would only have two prongs (IEC 60320 C8), and the label on a double-insulated charger in the UK usually has an icon consisting of two concentric squares. I suspect the audio circuitry in the Clevo W230SS is not very well designed, as there is virtually no hum from the same powered speakers if I plug them into the headphones socket of my Compal NBLB2 laptop while its mains charger, which has the same IEC 60320 C5/C6 coupler design as the Clevo laptop’s charger, is connected.

Now, I could have purchased a ground loop isolator, a passive device which is basically a couple of transformers (one per stereo channel), to interpose between the headphones socket on my laptop and the external powered speakers.

The YouTube video Solving Laptop Noise and Ground Loop Audio Interference contains a demonstration of what happens when you use a ground loop isolator on the headphones output of a laptop, and what happens when you use a double-insulated mains charger (two-prong coupler, rather than three-prong).

However, rather than buy a ground loop isolator I decided to try an active device, and purchased the XQ-10 portable headphones amplifier manufactured by Chinese company xDuoo. The XQ-10 is compact, fitting in the palm of my hand and weighing only 30 grammes. It has an aluminium-alloy case, and looks and feels well-made. Two cables are supplied: a USB cable to connect the XQ-10 to a phone charger or laptop in order to charge the LiPo battery in the XQ-10 (about 2 hours to charge, and about 20 hours of use on battery power), and a short 3.5 mm jack cable (male jack at both ends) to connect the XQ-10 to your laptop or phone.

xDuoo XQ-10

If the XQ-10’s USB charging cable is not connected (see the photograph above) then the loud hum from my external powered speakers still occurs. But with both cables connected (see the photograph below), the XQ-10 does the job perfectly: there is no hum or hiss, even when I turn the speakers’ volume knob to maximum.

xDuoo XQ-10

Although I do not need to use a headphones amplifier with the laptop when I use headphones or earphones — the volume is fine and there is no hum from headphones/earphones — I should mention that audio quality from my headphones and earphones connected to the XQ-10 is excellent (both with and without the USB charging cable connected, which is not surprising given that no earth loop exists when headphones/earphones are connected).

By the way, shop around if you do decide to buy the XQ-10, because its price on-line varies a lot. I paid GBP 17.95 for mine, and that included p&p.

Fixing all-white log-in screen when using the LightDM KDE greeter with Plasma 5 in Gentoo Linux

In a previous post I explained how I got LightDM to work on my Clevo W230SS laptop running KDE Plasma 5 in Gentoo Linux (Stable Branch). However, following a world update a few weeks later, the LightDM log-in screen (‘greeter’) became all white. Searching the Web showed me that this is a common problem with LightDM, although the cause appeared to be different in many other cases, as I could still see the password-entry box and the button to select the session.

To summarise what was already installed:

fitzcarraldo@clevow230ss ~ $ uname -a
Linux clevow230ss 3.18.11-gentoo #47 SMP Thu May 26 11:03:29 BST 2016 x86_64 Intel(R) Core(TM) i7-4810MQ CPU @ 2.80GHz GenuineIntel GNU/Linux
fitzcarraldo@clevow230ss ~ $ eix -I plasma-meta
[I] kde-plasma/plasma-meta
     Available versions:  (5) 5.6.5 ~5.7.3
       {bluetooth +display-manager grub gtk +handbook mediacenter networkmanager pam plymouth pulseaudio +sddm sdk +wallpapers}
     Installed versions:  5.6.5(5)(12:28:08 26/07/16)(bluetooth display-manager gtk handbook networkmanager pam pulseaudio wallpapers -grub -mediacenter -plymouth -sddm -sdk)
     Homepage:            https://www.kde.org/workspaces/plasmadesktop/
     Description:         Merge this to pull in all Plasma 5 packages

fitzcarraldo@clevow230ss ~ $ eix -I lightdm
[I] x11-misc/lightdm
     Available versions:  1.10.5^t 1.16.7^t ~1.17.6^t ~1.18.1^t ~1.19.0^t ~1.19.3^t {audit +gnome +gtk +introspection kde qt4 qt5}
     Installed versions:  1.16.7^t(04:11:41 23/08/16)(introspection kde qt4 qt5 -audit -gnome -gtk)
     Homepage:            https://www.freedesktop.org/wiki/Software/LightDM
     Description:         A lightweight display manager

[I] x11-misc/lightdm-kde
     Available versions:  (4) 0.3.2.1-r1
       {aqua debug L10N="bs cs da de el es et fi fr ga gl hu it ja km lt mr nds nl pl pt pt-BR ro ru sk sl sv tr uk"}
     Installed versions:  0.3.2.1-r1(4)(01:13:13 12/07/16)(-aqua -debug L10N="pt-BR -bs -cs -da -de -el -es -et -fi -fr -ga -gl -hu -it -ja -km -lt -mr -nds -nl -pl -pt -ro -ru -sk -sl -sv -tr -uk")
     Homepage:            https://projects.kde.org/projects/playground/base/lightdm
     Description:         LightDM KDE greeter

Found 2 matches

And this is what I had previously configured:

fitzcarraldo@clevow230ss ~ $ grep -v ^# /etc/lightdm/lightdm.conf
[LightDM]

session-wrapper=/etc/lightdm/Xsession
[Seat:*]
greeter-session=lightdm-kde-greeter
session-wrapper=/etc/lightdm/Xsession
display-setup-script=/etc/X11/Sessions/plasma

[XDMCPServer]

[VNCServer]
fitzcarraldo@clevow230ss ~ $ cat /etc/X11/Sessions/plasma
#!/bin/bash
GPU=`eselect opengl list | grep \* | awk '{ print $2 }'`
if [ "$GPU" = "nvidia" ]; then
    xrandr --setprovideroutputsource modesetting NVIDIA-0
    xrandr --auto
fi

Now, given that I had installed the LightDM KDE Greeter, I would have expected there to be a default configuration file lightdm-kde-greeter.conf for it, but there was none:

fitzcarraldo@clevow230ss ~ $ ls /etc/lightdm/
Xsession  keys.conf  lightdm.conf  users.conf

So I created the file /etc/lightdm/lightdm-kde-greeter.conf with the following contents:

[greeter]
theme-name=classic

[greeter-settings]
Background=/home/fitzcarraldo/Pictures/Wallpaper/Linux/kde-1920x1080.jpg
BackgroundKeepAspectRatio=true
GreetMessage=Welcome to %hostname%

I downloaded a nice KDE wallpaper file from the Web, which I saved as /home/fitzcarraldo/Pictures/Wallpaper/Linux/kde-1920x1080.jpg, but you can save it anywhere you like and give it any name you want.

I found that the package manager had installed two themes, so I could have specified either:

fitzcarraldo@clevow230ss ~ $ ls /usr/share/apps/lightdm-kde-greeter/themes/
classic  userbar

Anyway, the outcome is that the LightDM login screen (greeter) is no longer white and displays a wallpaper of my choice. Mission accomplished.

Text too small in X Windows when using nvidia-drivers

In an earlier post titled ‘Switching between Intel and NVIDIA graphics processors on a laptop with NVIDIA Optimus hardware running Gentoo Linux‘ I described how I am able to switch between the closed-source NVIDIA video driver and the open-source Intel video driver on a Clevo W230SS laptop with NVIDIA Optimus hardware. This works nicely, but one thing had been niggling me for over a year: the size of the fonts in the Desktop Environment were much smaller when using the NVIDIA driver than when using the Intel driver. I could of course increase the font size via KDE’s ‘System Settings’ > ‘Font’ when using the NVIDIA driver, but then I would have to reduce the font size the same way when using the Intel driver. So I resolved to find a better way, and it turned out all I needed to do was add one line to the Monitor section in xorg.conf to specify the DPI (Dots Per Inch) for the X Screen when using the NVIDIA driver:

Section "Monitor"
    Identifier     "Monitor0"
    Option         "DPMS"
    Option         "DPI" "96 x 96"
EndSection

You can read more about this in the NVIDIA Accelerated Linux Graphics Driver README and Installation Guide, Appendix B. X Config Options.

As described in my earlier post, I run a script to copy a file I named xorg.conf.nvidia to xorg.conf when I want to use the NVIDIA driver, and another script to copy a file I named xorg.conf.intel to xorg.conf when I want to use the Intel driver. So all I needed to do was add the line Option "DPI" "96 x 96" to the Monitor section in the file xorg.conf.nvidia and run my script to switch to the NVIDIA driver. Problem finally solved.

Getting KDE Plasma 5 to work with the NVIDIA closed-source driver in Gentoo Linux

Up until a few days ago I had avoided migrating from KDE 4 to KDE Plasma 5, Frameworks 5 and Applications 5 — I’ll refer to the latter three package categories collectively as ‘KDE:5’ — on my main laptop, a Clevo W230SS with NVIDIA Optimus hardware and Gentoo Linux Stable Branch installed. My reluctance to migrate to KDE:5 was because of various problems I experience in KDE:5 on my Compal NBLB2 laptop, which has Gentoo Testing Branch installed (currently Plasma 5.7.1, which you would expect to be less buggy than Plasma 5.5.5 in the Gentoo Stable Branch).

Recently the maintainers of Gentoo’s KDE ebuilds removed some of the KDE 4 ebuilds and made some of the other ebuilds dependent on KDE:5. It became more complicated and convoluted to keep KDE 4 going, so I reluctantly threw in the towel and migrated to KDE:5 on my main laptop. I wish I could have kept KDE 4 on that machine, as KDE 4 worked extremely well (and looked great too).

My first problem after migrating was the infamous black screen in X Windows at start-up. Trying the various suggestions in the Gentoo Wiki did not help and, for the first time since I’ve owned the Clevo laptop, I was glad it has NVIDIA Optimus hardware as I was able to change from using nvidia-drivers to using xf86-video-intel, which got me to a usable Desktop after I switched desktop managers from SDDM (see the system log file error messages below) to LightDM.

Jul 17 04:32:37 clevow230ss sddm-helper[3245]: PAM unable to dlopen(/lib64/security/pam_systemd.so): /lib64/security/pam_systemd.so: cannot open shared object file: No such file or directory
Jul 17 04:32:37 clevow230ss sddm-helper[3245]: PAM adding faulty module: /lib64/security/pam_systemd.so

Although I had merged x11-misc/sddm with USE="-systemd" because my installation uses OpenRC, the above error messages made me suspect that something is wrong with the sddm-0.13.0-r3 ebuild, which is why I switched to LightDM.

However, using solely the Intel driver is not a long-term solution for me because DraftSight CAD software is slower with the Intel driver, so I was keen to get Plasma 5 working with the closed-source NVIDIA driver (I do not want to use Bumblebee).

I managed to get LightDM and Plasma 5 working with nvidia-drivers by doing the following:

  1. Merge x11-misc/lightdm.
  2. Re-merge kde-plasma/plasma-meta with USE="-sddm".
  3. Remove the x11-misc/sddm package and kde-plasma/sddm-kcm package by using the command ‘emerge --ask --depclean‘.
  4. Edit the file /etc/lightdm/lightdm.conf to add the line ‘greeter-session=lightdm-kde-greeter‘ as specified in Gentoo Wiki article LightDM.
  5. Edit the file /etc/lightdm/lightdm.conf to add the line ‘display-setup-script=/etc/X11/Sessions/plasma‘ (any file name would do).
  6. Create the above-mentioned Bash script /etc/X11/Sessions/plasma containing the following:
#!/bin/bash
GPU=`eselect opengl list | grep \* | awk '{ print $2 }'`
if [ "$GPU" = "nvidia" ]; then
    xrandr --setprovideroutputsource modesetting NVIDIA-0
    xrandr --auto
fi

I can now switch between the NVIDIA closed-source driver and the Intel open-source driver using the method described in an earlier post: Switching between Intel and NVIDIA graphics processors on a laptop with NVIDIA Optimus hardware running Gentoo Linux.

No sound from headphones after resume from suspension / No sound from headphones after re-plug

It is not difficult to find posts on the Web regarding certain models of laptop that no longer produce sound from headphones after resuming from suspension, or no longer produce sound from their speakers or from headphones if you unplug and reconnect the headphones. My Clevo W230SS laptop suffered from these problems and more: sometimes the external microphone socket would no longer work either. I had to reboot the laptop in order to get audio working properly again.

The cause of these problems varies according to the specific hardware and software, and here I will describe a couple of fixes I implemented in Gentoo Linux for my Clevo W230SS laptop. Bear in mind that what works for one model of laptop may not necessarily work for a different model even if the symptoms are the same.

PROBLEM 1: No sound from headphones after resume from suspension

After my laptop resumed from suspension, headphones would no longer work until I rebooted the laptop. Sometimes an external microphone would also stop working until I rebooted. In 2014, Ubuntu user Kiril filed a bug report regarding this problem with the Clevo W230SS: [W230SS, VIA VT1802, Green Headphone Out, Front] No sound after suspend/resume. Actually, his original title for the bug report was: ‘[W230SS, VIA VT1802, Green Headphone Out, Front] No sound after fresh boot’. I didn’t have that problem: the headphone socket of my Clevo W230SS did produce sound after a ‘fresh boot’. Regarding Kiril‘s initial problem, ALSA developer Raymond Yau made several comments, including the following:

driver should not use same audio output for device 0 and device 2

independent headphone should be disabled on notebook by default

for desktop line out and headphone connected to different audio output nodes 0x03 and 0x04

this allow you to play different audio to line out and headphone

but this feature usually should be disabled for notebook

you need to file an upstream bug report to fix this bug in the indep_hp_possible function which should return false when there is no internal mic since some notebook have line out, headphone and Mic jack to support 5.1 or only enabled when headphone at extra front and line out at ext rear

the workaround is use hint to disable the indep_hp=0

https://git.kernel.org/cgit/linux/kernel/git/tiwai/sound.git/tree/Documentation/sound/alsa/HD-Audio.txt

Now, Kiril was using Ubuntu 14.04 and ALSA 1.0.27, whereas I’m using Gentoo and ALSA 1.0.29. Furthermore, apart from the two installations using different kernel versions, in Gentoo you configure and build the kernel yourself. So there is quite some difference between the two installations, which might explain why I do not have his original problem of no sound from headphones after a fresh boot. Where we did coincide, though, was that there was no sound from headphones following resumption from suspension.

First attempt at fixing the problem

Even though Independent HP does not stop headphones working after I boot my laptop, I decided to try to remove Independent HP anyway, to see if it would fix the suspend/resume problem with headphones in my case.

The Clevo W230SS has two sound cards:

root # lspci | grep Audio
00:03.0 Audio device: Intel Corporation Xeon E3-1200 v3/4th Gen Core Processor HD Audio Controller (rev 06)
00:1b.0 Audio device: Intel Corporation 8 Series/C220 Series Chipset High Definition Audio Controller (rev 05)

The HDMI audio card is Card 0, and the analogue HD Audio card is Card 1. ALSAMixer shows an Independent HP (headphone) channel for Card 1:

user $ alsamixer -c 1

The kernel documentation for the HD Audio driver explains how to fix the problem using what is called a driver ‘hint’. There is a link to the documentation in the above-mentioned bug report, and you can also find the documentation in the file /usr/src/<kernel_release>/Documentation/sound/alsa/HD-Audio.txt on your laptop if you have installed the kernel source code. As explained in the documentation, you can remove Independent HP either via the command line:

root # echo "indep_hp = no" > /sys/class/sound/hwC1D0/hints
root # echo 1 > /sys/class/sound/hwC1D0/reconfig

or by using so-called ‘Early Patching’:

Early Patching
~~~~~~~~~~~~~~
When CONFIG_SND_HDA_PATCH_LOADER=y is set, you can pass a "patch" as a
firmware file for modifying the HD-audio setup before initializing the
codec.  This can work basically like the reconfiguration via sysfs in
the above, but it does it before the first codec configuration.

Note that the term ‘patching’ here has nothing to do with patching the driver’s source code; it refers to patching the ALSA driver’s configuration of the VIA chip’s CODEC on the Intel sound card.

The format of this particular patch file containing a ‘hint’ would be as follows:

[codec]
<vendor_id> <subsystem_id> <address_of_the_CODEC>

[hint]
indep_hp = no

The values for vendor_id and subsystem_id can be found as follows:

root # cat /sys/class/sound/hwC1D0/vendor_id
0x11068446
root # cat /sys/class/sound/hwC1D0/subsystem_id
0x15582300

(As the driver is used with Card 1, remember to look in directory hwC1D0 rather than hwC0D0.)

The required value for address_of_the_CODEC is zero in this particular case. Therefore the file /lib/firmware/clevo-hda-patch (you can choose any file name you want) should have the following contents:

[codec]
0x11068446 0x15582300 0

[hint]
indep_hp = no

If you built the HA Audio driver as a module, you would need to add the following line to the file /etc/modprobe.d/alsa.conf in order to apply the patch:

options snd-hda-intel patch=,clevo-hda-patch

Notice the comma after the equals sign. This is required because the patch applies to the second card (Card 1) rather than to the first card (Card 0).

However, I had built the HD Audio driver into the kernel rather than as a module:

root # grep HDA /usr/src/linux/.config | grep -v "is not set"
CONFIG_SND_HDA=y
CONFIG_SND_HDA_INTEL=y
CONFIG_SND_HDA_PREALLOC_SIZE=2048
CONFIG_SND_HDA_HWDEP=y
CONFIG_SND_HDA_RECONFIG=y
CONFIG_SND_HDA_INPUT_BEEP=y
CONFIG_SND_HDA_INPUT_BEEP_MODE=1
CONFIG_SND_HDA_INPUT_JACK=y
CONFIG_SND_HDA_PATCH_LOADER=y
CONFIG_SND_HDA_CODEC_VIA=y
CONFIG_SND_HDA_CODEC_HDMI=y
CONFIG_SND_HDA_I915=y
CONFIG_SND_HDA_GENERIC=y
CONFIG_SND_HDA_POWER_SAVE_DEFAULT=0

Therefore adding the option to /etc/modprobe.d/alsa.conf would have no effect, as the HD Audio driver is not a module. In this case I could have appended the following parameter to the kernel boot line in the file /boot/grub/grub.cfg instead:

snd-hda-intel.patch=,clevo-hda-patch

The above kernel boot parameter could be appended to the kernel boot line either directly by editing the file grub.cfg, or indirectly by adding it to the list of boot parameters in the variable GRUB_CMDLINE_LINUX_DEFAULT="" in the file /etc/default/grub and then using the command ‘grub2-mkconfig -o /boot/grub/grub.cfg‘ as root user to regenerate the grub.cfg file. Remember to mount /boot first if it is on a different partition.

Now, I tried applying the patch using the appropriate method in each case: HD Audio driver built into the kernel, and HD Audio driver built as a module (it didn’t take me long to modify the kernel configuration and rebuild the kernel). In both cases the following messages were included in the output of the dmesg command:

[ 0.430218] snd_hda_intel 0000:00:1b.0: Applying patch firmware 'clevo-hda-patch'
[ 0.430356] snd_hda_intel 0000:00:1b.0: Direct firmware load for clevo-hda-patch failed with error -2
[ 0.430359] snd_hda_intel 0000:00:1b.0: Cannot load firmware, aborting

I’m not sure if the reason for the failure to load the patch is the same in both cases, but certainly the reason in the case of the module is that PulseAudio is already running and using the driver by the time the OS attempts to apply the patch. In the case of the kernel boot parameter, my guess is that the patch would need to be included in an initramfs in order to be able to apply it before PulseAudio starts.

The same situation occurs if you try to apply the ‘hint’ manually from the command line after start-up:

root # echo "indep_hp = no" > /sys/class/sound/hwC1D0/hints
root # echo 1 > /sys/class/sound/hwC1D0/reconfig
bash: echo: write error: Device or resource busy

The above error message occurs because PulseAudio is running and using the driver. To apply the hint and refresh the driver in this case, the solution is to stop PulseAudio beforehand:

user $ echo "autospawn = no" >> ~/.config/pulse/client.conf
user $ pulseaudio --kill
user $ su
root # echo "indep_hp = no" > /sys/class/sound/hwC1D0/hints
root # echo 1 > /sys/class/sound/hwC1D0/reconfig
root # exit
user $ pulseaudio --start

Now, having to do the above manually every time you boot your machine is impractical. To automate the procedure I did the following…

Make sure the automatic (re)spawning of PulseAudio is disabled in the file ~/.config/pulse/client.conf (you can create the file if it does not exist):

autospawn = no

Create a Bash script in the directory /etc/local.d/ for the OS to launch automatically at boot, and in that script issue the above two commands first and then start pulseaudio. I named the script ‘99-clevo-hda-fix.start‘ and made its contents the following:

#!/bin/bash
# Fix for Intel HDA problem with Clevo W230SS
# See https://bugs.launchpad.net/ubuntu/+source/alsa-driver/+bug/1313904
# N.B. Assumes your ~/.config/pulse/client.conf contains
# 'autospawn = no' so that PulseAudio is not launched automatically.
#
# Specify the hint
echo "indep_hp = no" > /sys/class/sound/hwC1D0/hints
#
# Reinitialise the HD Audio driver so it parses the CODEC tree again
echo 1 > /sys/class/sound/hwC1D0/reconfig
#
# Start PulseAudio for my user account
su -c "pulseaudio --start" -s /bin/sh fitzcarraldo

Don’t forget to make the script executable:

root # chmod +x /etc/local.d/99-clevo-hda-fix.start

This method of applying the hint to the HD Audio driver should work irrespectively of whether the driver is a module or built-in. It’s a bit more of a hack compared to the Early Patching approach, but it does the job in my case. After logging in to the Desktop Environment, you can check if the hint has been applied by looking at the contents of /sys/class/sound/hwC1D0/hints:

root # cat /sys/class/sound/hwC1D0/hints
indep_hp = no

However, this alone does not mean the CODEC was reconfigured after the hint was applied, so you need to check if Independent HP still exists. The ALSAMixer output on my laptop now looked like the following after I implemented the above method (notice that Independent HP no longer exists):

user $ alsamixer -c 1

So, what was the result? Well, audio continued to work after I removed Independent HP, but there was still no sound from headphones after resuming from suspension. And neither was there for Kiril, so he changed the title of his bug report to that effect. Fortunately, another user, unrud, commented later in the bug report that he had written init-headphone, a Python script to fix the problem. So I decided to hack his Ubuntu package to get init-headphone working in my Gentoo Linux installation. Here is how I did it…

Second (successful!) attempt at fixing the problem

1. Download init-headphone-ubuntu-0.11.zip from https://github.com/Unrud/init-headphone-ubuntu/releases

2. Extract the contents to the directory ~/init-headphone-ubuntu-0.11/

3. Copy to pm-utils’ hook directory the script that launches init-headphone upon resuming or thawing:

root # cp /home/fitzcarraldo/init-headphone-ubuntu-0.11/etc/linux-pm-utils/init-headphone /etc/pm/sleep.d/03-init-headphone # (use whatever number you want)

4. Copy the init-headphone script itself to the system binaries directory:

root # cp /home/fitzcarraldo/init-headphone-ubuntu-0.11/src/init-headphone /usr/local/sbin/

5. The init-headphone script requires the i2c_dev and i2c_i801 modules:

REQUIRED_MODULES = ["i2c_dev", "i2c_i801"]

However, I prefer to build them into the kernel rather than as modules, so I checked to make sure they are already built into the kernel:

root # grep CONFIG_I2C /usr/src/linux/.config | grep -v "is not set"
CONFIG_I2C=y
CONFIG_I2C_BOARDINFO=y
CONFIG_I2C_COMPAT=y
CONFIG_I2C_CHARDEV=y
CONFIG_I2C_MUX=y
CONFIG_I2C_HELPER_AUTO=y
CONFIG_I2C_ALGOBIT=y
CONFIG_I2C_I801=y

Then I commented out the lines in /usr/local/sbin/init-headphone that check if the two modules are loaded:

root # diff /home/fitzcarraldo/init-headphone-ubuntu-0.11/src/init-headphone /usr/local/sbin/init-headphone
174,181c174,181
< def check_modules():
< try:
< for module in REQUIRED_MODULES:
< logging.info("Trying to add module to the kernel: %s", module)
< if subprocess.call(["modprobe", "--quiet", module]) != 0:
< logging.warning("Module is not loaded: %s", module)
< except OSError:
#def check_modules():
> # try:
> # for module in REQUIRED_MODULES:
> # logging.info("Trying to add module to the kernel: %s", module)
> # if subprocess.call(["modprobe", "--quiet", module]) != 0:
> # logging.warning("Module is not loaded: %s", module)
> # except OSError:
> # logging.warning("modprobe not found")
206c206
# check_modules()

6. I created a script /etc/local.d/99-clevo-hda-fix.start to launch init-headphone automatically at boot:

#!/bin/bash
# Fix for Intel HDA problem with Clevo W230ss
# See https://bugs.launchpad.net/ubuntu/+source/alsa-driver/+bug/1313904
exec /usr/local/sbin/init-headphone

root # chmod +x /etc/local.d/99-clevo-hda-fix.start

7. Add the kernel boot parameter ‘acpi_enforce_resources=lax‘ to the end of the kernel boot line(s) in /boot/grub/grub.cfg (don’t forget to mount /boot first if it is on another partition). You can either edit /boot/grub/grub.cfg directly, or indirectly by adding the parameter to the list of existing parameters in GRUB_CMDLINE_LINUX_DEFAULT (if any) as shown below and issuing the command ‘grub2-mkconfig -o /boot/grub/grub.cfg‘ as root user (again, don’t forget to mount /boot first if it is on another partition):

GRUB_CMDLINE_LINUX_DEFAULT="acpi_enforce_resources=lax"

8. Create a script file /etc/local.d/99-clevo-hda-fix.start to launch the init-headphone automatically at boot:

#!/bin/bash
# Fix for Intel HDA problem with Clevo W230SS
# See https://bugs.launchpad.net/ubuntu/+source/alsa-driver/+bug/1313904
exec /usr/local/sbin/init-headphone

9. As my user account does not have a path configured to the system binaries directory, I created a symlink to it from the directory /usr/local/bin/:

root # ln -s /usr/local/sbin/init-headphone /usr/local/bin/init-headphone

10. As I no longer needed to stop PulseAudio running at boot, I deleted the file /home/fitzcarraldo/.config/pulse/client.conf I had created earlier (or you could just change ‘autospawn = no‘ to ‘autospawn = yes‘).

You can also use init-headphone from the command line:

user $ sudo init-headphone --help

e.g.

user $ sudo init-headphone unmute

This looks like it has finally solved the problem; now headphones still work after my laptop resumes from suspension. I still don’t need to pass the ‘hint’ to the HD Audio driver, so Independent HP continues to appear in ALSAMixer and apparently does not cause any problems.

A big ‘Thank you’ from me to Unrud for creating init-headphone.

PROBLEM 2: No sound from headphones after re-plug

The other problem I experienced with the Clevo W230SS was that, if I unplugged working headphones, audio switched to the laptop’s speakers as expected, but, if I then plugged-in the headphones again, no more sound came from the headphones. If I again unplugged the headphones, sound would again come from the speakers. If I did all this whilst ALSAMixer was running, then:

  1. if I unplugged the headphones, as expected the ALSAMixer volume level indicator for the speaker would rise from zero and the volume level indicator for the headphones would drop to zero;
  2. if I plugged in the headphones, as expected the ALSAMixer volume level indicator for the speaker would drop to zero and the volume level indicator for the headphones would rise from zero.

Now, it is possible that this problem was due to the same thing that caused the loss of audio to headphones when the laptop resumed from suspension. Anyway, before I came across init-headphone I found the following in the Arch Linux Wiki article on PulseAudio:

Switch on connect

This is a module used to switch the output sound to the newly connected device. For example, if you plug in a USB headset, the output will be switched to that. If you unplug it, the output will be set back to the last device. This used to be quite buggy but got a lot of attention in PulseAudio 8.0 and should work quite well now.

If you just want to test the module then you can load it at runtime by calling:

root # pactl load-module module-switch-on-connect

If you want to make the change persistent you will have to add it to your local pulseaudio settings or to /etc/pulse/default.pa (system wide effect). In either case, add this line:

load-module module-switch-on-connect

So, as the file /etc/pulse/default.pa in my installation did not have that line, I added it:

# Added by fitzcarraldo
# https://wiki.archlinux.org/index.php/PulseAudio
# The headphone socket no longer worked if I
# removed and re-inserted the jack plug.
load-module module-switch-on-connect

This seemed to help, but I am not certain module-switch-on-connect is really having an effect when I plug and unplug headphones, and I have not bothered to disable it to see what happens now that init-headphone is in use (I’m just happy that audio is all working now, whatever the reason!). ALSA’s Auto-Mute Mode* appears to perform the same role as module-switch-on-connect: When I unplug the headphones with Auto-Mute Mode enabled in ALSAMixer, there is a noticeable delay before sound starts to come from the laptop’s speakers, whereas there is no such delay when I unplug the headphones with Auto-Mute Mode disabled via ALSAMixer, so presumably module-switch-on-connect is doing its job.

* The documentation file /usr/src/<kernel_release>/Documentation/sound/alsa/HD-Audio-Controls.txt explains what Auto-Mute Mode does.

Anyhow, one or both of the two software modifications (init-headphone and module-switch-on-connect) seem to have cured the problem of no sound from headphones after they are disconnected then reconnected to the laptop.

Installing DraftSight 2016 Pre-Release in Gentoo Linux

Last year I posted about installing the 2015 Draftsight Free 2D CAD application in Gentoo Linux. Now a DraftSight 2016 Pre-Release is available, and it works in Gentoo. Dassault Systemes has fixed the annoying cursor lag in the 2015 Linux version. \o/

You can click on a link ‘Download DraftSight 2016 for Ubuntu (beta)’ on their Web page ‘DraftSight® FREE* CAD Software Download‘ and copy the downloaded file draftSight.deb to /usr/portage/distfiles/draftsight-1.7.0_beta.deb. Then rename the ebuild draftsight-bin-1.6.1_beta.ebuild to draftsight-bin-1.7.0_beta.ebuild in your local overlay directory /usr/local/portage/media-gfx/draftsight-bin/, but draftsight-bin-1.7.0_beta.ebuild is listed below anyway:

# Copyright 1999-2016 Gentoo Foundation
# Distributed under the terms of the GNU General Public License v2
# $Header: $

EAPI=5

inherit fdo-mime udev unpacker

MY_PN="draftsight"
MY_P="${MY_PN}-${PV}"
DESCRIPTION="Professional 2D CAD application, supporting DWT, DXF and DWG."
HOMEPAGE="http://www.3ds.com/products/draftsight/free-cad-software/"
SRC_URI="${MY_P}.deb"

LICENSE="${MY_PN}"
SLOT="0"
KEYWORDS="~amd64"
IUSE=""
S="${WORKDIR}"

QA_PRESTRIPPED="opt/dassault-systemes/${MY_PN}/bin/DWGConverter
	amd64? ( opt/dassault-systemes/${MY_PN}/lib/libaudio.so.2 )"
QA_TEXTRELS="opt/dassault-systemes/${MY_PN}/lib/libDDKERNEL.so.1"
QA_EXECSTACK="opt/dassault-systemes/${MY_PN}/bin/FxCrashRptApp
opt/dassault-systemes/${MY_PN}/lib/libDDKERNEL.so.1"

RESTRICT="fetch"
DEPEND=""
RDEPEND="amd64? (
		sys-libs/zlib
		net-print/cups
		dev-libs/expat
		dev-libs/glib:2
		media-libs/glu
		media-libs/phonon
		dev-qt/qtcore:4
		dev-qt/qtdbus:4
		dev-qt/qtgui:4
		dev-qt/qtopengl:4
		dev-qt/qtsql:4
		dev-qt/qtwebkit:4
		dev-qt/qtsvg:4
		media-libs/alsa-lib
		media-libs/fontconfig
		media-libs/freetype
		x11-libs/libICE
		x11-libs/libSM
		x11-libs/libX11
		x11-libs/libXext
		x11-libs/libXrender
		x11-libs/libXt
		media-libs/nas
		)"

pkg_nofetch() {
	einfo "Upstream has a mandatory EULA agreement to download this file."
	einfo "Please navigate your browser to:"
	einfo "http://www.3ds.com/products-services/draftsight-cad-software/free-download/"
	einfo "Click \"Download DraftSight 2015 for Ubuntu (beta)\""
	einfo "Download the deb file and move it to ${DISTDIR}/${MY_P}.deb"
}

src_install() {
	cp -R "${WORKDIR}/opt" "${D}"
	exeinto /usr/bin
	doexe "${FILESDIR}/${MY_PN}"

	# prepare for dongle
	udev_dorules "${FILESDIR}"/10-ft-rockey.rules
}

pkg_postinst() {
	elog "To use DraftSight as your default viewer for DWG, DXF, and DWT"
	elog "Please run the following commands respectively as your normal user:"
	elog "xdg-mime default \"dassault-systemes\"_\"draftsight.desktop\" \"application/vnd.dassault-systemes.draftsight-dwg\""
	elog "xdg-mime default \"dassault-systemes\"_\"draftsight.desktop\" \"application/vnd.dassault-systemes.draftsight-dxf\""
	elog "xdg-mime default \"dassault-systemes\"_\"draftsight.desktop\" \"application/vnd.dassault-systemes.draftsight-dwt\""

	fdo-mime_desktop_database_update
	fdo-mime_mime_database_update

	for size in 16 32 48 64 128 ; do
		local XDG_OPTS="--noupdate --novendor --mode system --size ${size}"
		xdg-icon-resource install ${XDG_OPTS} --context apps \
			"${ROOT}/opt/dassault-systemes/DraftSight/Resources/pixmaps/${size}x${size}/program.png" \
			"dassault-systemes.draftsight"
		xdg-icon-resource install ${XDG_OPTS} --context apps --theme gnome \
			"${ROOT}/opt/dassault-systemes/DraftSight/Resources/pixmaps/${size}x${size}/program.png" \
			"dassault-systemes.draftsight"
		for mimetype in dwg dxf dwt ; do
			xdg-icon-resource install ${XDG_OPTS} --context mimetypes \
				"${ROOT}/opt/dassault-systemes/DraftSight/Resources/pixmaps/${size}x${size}/file-${mimetype}.png" \
				"application-vnd.dassault-systemes.draftsight-${mimetype}"
			xdg-icon-resource install ${XDG_OPTS} --context mimetypes --theme gnome \
				"${ROOT}/opt/dassault-systemes/DraftSight/Resources/pixmaps/${size}x${size}/file-${mimetype}.png" \
				"application-vnd.dassault-systemes.draftsight-${mimetype}"
		done
	done
	xdg-icon-resource forceupdate
}

pkg_postrm() {
	fdo-mime_desktop_database_update
	fdo-mime_mime_database_update
	for size in 16 32 48 64 128 ; do
		xdg-icon-resource uninstall --noupdate --context apps --mode system \
			--size ${size} "dassault-systemes.draftsight"
		xdg-icon-resource uninstall --noupdate --context apps --mode system --theme gnome \
			--size ${size} "dassault-systemes.draftsight"
		for mimetype in dwg dxf dwt ; do
			xdg-icon-resource uninstall --noupdate --context mimetypes --mode system \
				--size ${size} "application-vnd.dassault-systemes.draftsight-${mimetype}"
			xdg-icon-resource uninstall --noupdate --context mimetypes --mode system --theme gnome \
				--size ${size} "application-vnd.dassault-systemes.draftsight-${mimetype}"
		done
	done
	xdg-icon-resource forceupdate
}

The files 10-ft-rockey.rules and draftsight in the directory /usr/local/portage/media-gfx/draftsight-bin/files/ can stay the same as for the previous ebuild draftsight-bin-1.6.1_beta.ebuild, but they are listed below anyway:

BUS=="usb", SYSFS{idVendor}=="096e", MODE=="0666"

#! /bin/bash
BASEDIR="/opt/dassault-systemes/DraftSight/Linux"

export LD_LIBRARY_PATH="${BASEDIR}${LD_LIBRARY_PATH:+:}${LD_LIBRARY_PATH}"

# work around DT_RPATH (.) security issue by chdir'ing into expected $LD_LIBRARY_PATH
cd "${BASEDIR}"

exec "${BASEDIR}/DraftSight" $*

Then generate the manifest as usual and merge the package.
